support more inference features: tile, alpha channel, gray image, 16-bit

inference_realesrgan.py

@@ -1,6 +1,7 @@
 import argparse
 import cv2
 import glob
+import math
 import numpy as np
 import os
 import torch
@@ -10,64 +11,233 @@ from torch.nn import functional as F

 def main():
     parser = argparse.ArgumentParser()
-    parser.add_argument('--model_path', type=str, default='experiments/pretrained_models/RealESRGAN_x4plus.pth')
-    parser.add_argument('--scale', type=int, default=4)
-    parser.add_argument('--suffix', type=str, default='_out')
-    parser.add_argument('--input', type=str, default='inputs', help='input image or folder')
+    parser.add_argument('--input', type=str, default='inputs', help='Input image or folder')
+    parser.add_argument(
+        '--model_path',
+        type=str,
+        default='experiments/pretrained_models/RealESRGAN_x4plus.pth',
+        help='Path to the pre-trained model')
+    parser.add_argument('--scale', type=int, default=4, help='Upsample scale factor')
+    parser.add_argument('--suffix', type=str, default='out', help='Suffix of the restored image')
+    parser.add_argument('--tile', type=int, default=0, help='Tile size, 0 for no tile during testing')
+    parser.add_argument('--tile_pad', type=int, default=10, help='Tile padding')
+    parser.add_argument('--pre_pad', type=int, default=0, help='Pre padding size at each border')
+    parser.add_argument(
+        '--alpha_upsampler',
+        type=str,
+        default='realesrgan',
+        help='The upsampler for the alpha channels. Options: realesrgan | bicubic')
+    parser.add_argument(
+        '--extension',
+        type=str,
+        default='auto',
+        help='Image extension. Options: auto | jpg | png, auto means using the same extension as inputs')
     args = parser.parse_args()

-    device = torch.device('cuda' if torch.cuda.is_available() else 'cpu')
-    # set up model
-    model = RRDBNet(num_in_ch=3, num_out_ch=3, num_feat=64, num_block=23, num_grow_ch=32, scale=args.scale)
-    loadnet = torch.load(args.model_path)
-    if 'params_ema' in loadnet:
-        keyname = 'params_ema'
+    upsampler = RealESRGANer(
+        scale=args.scale, model_path=args.model_path, tile=args.tile, tile_pad=args.tile_pad, pre_pad=args.pre_pad)
+    os.makedirs('results/', exist_ok=True)
+    if os.path.isfile(args.input):
+        paths = [args.input]
     else:
-        keyname = 'params'
-    model.load_state_dict(loadnet[keyname], strict=True)
-    model.eval()
-    model = model.to(device)
+        paths = sorted(glob.glob(os.path.join(args.input, '*')))

-    os.makedirs('results/', exist_ok=True)
-    for idx, path in enumerate(sorted(glob.glob(os.path.join(args.input, '*')))):
-        imgname = os.path.splitext(os.path.basename(path))[0]
+    for idx, path in enumerate(paths):
+        imgname, extension = os.path.splitext(os.path.basename(path))
         print('Testing', idx, imgname)
-        # read image
-        img = cv2.imread(path, cv2.IMREAD_COLOR).astype(np.float32) / 255.
-        img = torch.from_numpy(np.transpose(img[:, :, [2, 1, 0]], (2, 0, 1))).float()
-        img = img.unsqueeze(0).to(device)
-
-        if args.scale == 2:
-            mod_scale = 2
-        elif args.scale == 1:
-            mod_scale = 4
+
+        # ------------------------------ read image ------------------------------ #
+        img = cv2.imread(path, cv2.IMREAD_UNCHANGED).astype(np.float32)
+        if np.max(img) > 255:  # 16-bit image
+            max_range = 65535
+            print('\tInput is a 16-bit image')
+        else:
+            max_range = 255
+        img = img / max_range
+        if len(img.shape) == 2:  # gray image
+            img_mode = 'L'
+            img = cv2.cvtColor(img, cv2.COLOR_GRAY2RGB)
+        elif img.shape[2] == 4:  # RGBA image with alpha channel
+            img_mode = 'RGBA'
+            alpha = img[:, :, 3]
+            img = img[:, :, 0:3]
+            img = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)
+            if args.alpha_upsampler == 'realesrgan':
+                alpha = cv2.cvtColor(alpha, cv2.COLOR_GRAY2RGB)
+        else:
+            img_mode = 'RGB'
+            img = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)
+
+        # ------------------- process image (without the alpha channel) ------------------- #
+        upsampler.pre_process(img)
+        if args.tile:
+            upsampler.tile_process()
+        else:
+            upsampler.process()
+        output_img = upsampler.post_process()
+        output_img = output_img.data.squeeze().float().cpu().clamp_(0, 1).numpy()
+        output_img = np.transpose(output_img[[2, 1, 0], :, :], (1, 2, 0))
+        if img_mode == 'L':
+            output_img = cv2.cvtColor(output_img, cv2.COLOR_BGR2GRAY)
+
+        # ------------------- process the alpha channel if necessary ------------------- #
+        if img_mode == 'RGBA':
+            if args.alpha_upsampler == 'realesrgan':
+                upsampler.pre_process(alpha)
+                if args.tile:
+                    upsampler.tile_process()
+                else:
+                    upsampler.process()
+                output_alpha = upsampler.post_process()
+                output_alpha = output_alpha.data.squeeze().float().cpu().clamp_(0, 1).numpy()
+                output_alpha = np.transpose(output_alpha[[2, 1, 0], :, :], (1, 2, 0))
+                output_alpha = cv2.cvtColor(output_alpha, cv2.COLOR_BGR2GRAY)
+            else:
+                h, w = alpha.shape[0:2]
+                output_alpha = cv2.resize(alpha, (w * args.scale, h * args.scale), interpolation=cv2.INTER_LINEAR)
+
+            # merge the alpha channel
+            output_img = cv2.cvtColor(output_img, cv2.COLOR_BGR2BGRA)
+            output_img[:, :, 3] = output_alpha
+
+        # ------------------------------ save image ------------------------------ #
+        if args.extension == 'auto':
+            extension = extension[1:]
+        else:
+            extension == args.extension
+        if img_mode == 'RGBA':  # RGBA images should be saved in png format
+            extension = 'png'
+        save_path = f'results/{imgname}_{args.suffix}.{extension}'
+        if max_range == 65535:  # 16-bit image
+            output = (output_img * 65535.0).round().astype(np.uint16)
+        else:
+            output = (output_img * 255.0).round().astype(np.uint8)
+        cv2.imwrite(save_path, output)
+
+
+class RealESRGANer():
+
+    def __init__(self, scale, model_path, tile=0, tile_pad=10, pre_pad=10):
+        self.scale = scale
+        self.tile_size = tile
+        self.tile_pad = tile_pad
+        self.pre_pad = pre_pad
+        self.mod_scale = None
+
+        # initialize model
+        self.device = torch.device('cuda' if torch.cuda.is_available() else 'cpu')
+        model = RRDBNet(num_in_ch=3, num_out_ch=3, num_feat=64, num_block=23, num_grow_ch=32, scale=scale)
+        loadnet = torch.load(model_path)
+        if 'params_ema' in loadnet:
+            keyname = 'params_ema'
         else:
-            mod_scale = None
-        if mod_scale is not None:
-            h_pad, w_pad = 0, 0
-            _, _, h, w = img.size()
-            if (h % mod_scale != 0):
-                h_pad = (mod_scale - h % mod_scale)
-            if (w % mod_scale != 0):
-                w_pad = (mod_scale - w % mod_scale)
-            img = F.pad(img, (0, w_pad, 0, h_pad), 'reflect')
+            keyname = 'params'
+        model.load_state_dict(loadnet[keyname], strict=True)
+        model.eval()
+        self.model = model.to(self.device)
+
+    def pre_process(self, img):
+        img = torch.from_numpy(np.transpose(img, (2, 0, 1))).float()
+        self.img = img.unsqueeze(0).to(self.device)
+
+        # pre_pad
+        if self.pre_pad != 0:
+            self.img = F.pad(self.img, (0, self.pre_pad, 0, self.pre_pad), 'reflect')
+        # mod pad
+        if self.scale == 2:
+            self.mod_scale = 2
+        elif self.scale == 1:
+            self.mod_scale = 4
+        if self.mod_scale is not None:
+            self.mod_pad_h, self.mod_pad_w = 0, 0
+            _, _, h, w = self.img.size()
+            if (h % self.mod_scale != 0):
+                self.mod_pad_h = (self.mod_scale - h % self.mod_scale)
+            if (w % self.mod_scale != 0):
+                self.mod_pad_w = (self.mod_scale - w % self.mod_scale)
+            self.img = F.pad(self.img, (0, self.mod_pad_w, 0, self.mod_pad_h), 'reflect')

+    def process(self):
         try:
             # inference
             with torch.no_grad():
-                output = model(img)
-            # remove extra pad
-            if mod_scale is not None:
-                _, _, h, w = output.size()
-                output = output[:, :, 0:h - h_pad, 0:w - w_pad]
-            # save image
-            output = output.data.squeeze().float().cpu().clamp_(0, 1).numpy()
-            output = np.transpose(output[[2, 1, 0], :, :], (1, 2, 0))
-            output = (output * 255.0).round().astype(np.uint8)
-            cv2.imwrite(f'results/{imgname}_{args.suffix}.png', output)
+                self.output = self.model(self.img)
         except Exception as error:
             print('Error', error)

+    def tile_process(self):
+        """Modified from: https://github.com/ata4/esrgan-launcher
+        """
+        batch, channel, height, width = self.img.shape
+        output_height = height * self.scale
+        output_width = width * self.scale
+        output_shape = (batch, channel, output_height, output_width)
+
+        # start with black image
+        self.output = self.img.new_zeros(output_shape)
+        tiles_x = math.ceil(width / self.tile_size)
+        tiles_y = math.ceil(height / self.tile_size)
+
+        # loop over all tiles
+        for y in range(tiles_y):
+            for x in range(tiles_x):
+                # extract tile from input image
+                ofs_x = x * self.tile_size
+                ofs_y = y * self.tile_size
+                # input tile area on total image
+                input_start_x = ofs_x
+                input_end_x = min(ofs_x + self.tile_size, width)
+                input_start_y = ofs_y
+                input_end_y = min(ofs_y + self.tile_size, height)
+
+                # input tile area on total image with padding
+                input_start_x_pad = max(input_start_x - self.tile_pad, 0)
+                input_end_x_pad = min(input_end_x + self.tile_pad, width)
+                input_start_y_pad = max(input_start_y - self.tile_pad, 0)
+                input_end_y_pad = min(input_end_y + self.tile_pad, height)
+
+                # input tile dimensions
+                input_tile_width = input_end_x - input_start_x
+                input_tile_height = input_end_y - input_start_y
+                tile_idx = y * tiles_x + x + 1
+                input_tile = self.img[:, :, input_start_y_pad:input_end_y_pad, input_start_x_pad:input_end_x_pad]
+
+                # upscale tile
+                try:
+                    with torch.no_grad():
+                        output_tile = self.model(input_tile)
+                except Exception as error:
+                    print('Error', error)
+                print(f'\tTile {tile_idx}/{tiles_x * tiles_y}')
+
+                # output tile area on total image
+                output_start_x = input_start_x * self.scale
+                output_end_x = input_end_x * self.scale
+                output_start_y = input_start_y * self.scale
+                output_end_y = input_end_y * self.scale
+
+                # output tile area without padding
+                output_start_x_tile = (input_start_x - input_start_x_pad) * self.scale
+                output_end_x_tile = output_start_x_tile + input_tile_width * self.scale
+                output_start_y_tile = (input_start_y - input_start_y_pad) * self.scale
+                output_end_y_tile = output_start_y_tile + input_tile_height * self.scale
+
+                # put tile into output image
+                self.output[:, :, output_start_y:output_end_y,
+                            output_start_x:output_end_x] = output_tile[:, :, output_start_y_tile:output_end_y_tile,
+                                                                       output_start_x_tile:output_end_x_tile]
+
+    def post_process(self):
+        # remove extra pad
+        if self.mod_scale is not None:
+            _, _, h, w = self.output.size()
+            self.output = self.output[:, :, 0:h - self.mod_pad_h * self.scale, 0:w - self.mod_pad_w * self.scale]
+        # remove prepad
+        if self.pre_pad != 0:
+            _, _, h, w = self.output.size()
+            self.output = self.output[:, :, 0:h - self.pre_pad * self.scale, 0:w - self.pre_pad * self.scale]
+        return self.output
+

 if __name__ == '__main__':
     main()
