Add zynq7000 bsp

bsp/zynq/zynq7000/.config

@@ -0,0 +1,1034 @@
+#
+# Automatically generated file; DO NOT EDIT.
+# RT-Thread Project Configuration
+#
+
+#
+# RT-Thread Kernel
+#
+CONFIG_RT_NAME_MAX=8
+# CONFIG_RT_USING_ARCH_DATA_TYPE is not set
+# CONFIG_RT_USING_SMART is not set
+# CONFIG_RT_USING_AMP is not set
+# CONFIG_RT_USING_SMP is not set
+CONFIG_RT_ALIGN_SIZE=8
+# CONFIG_RT_THREAD_PRIORITY_8 is not set
+CONFIG_RT_THREAD_PRIORITY_32=y
+# CONFIG_RT_THREAD_PRIORITY_256 is not set
+CONFIG_RT_THREAD_PRIORITY_MAX=32
+CONFIG_RT_TICK_PER_SECOND=1000
+CONFIG_RT_USING_OVERFLOW_CHECK=y
+CONFIG_RT_USING_HOOK=y
+CONFIG_RT_HOOK_USING_FUNC_PTR=y
+CONFIG_RT_USING_IDLE_HOOK=y
+CONFIG_RT_IDLE_HOOK_LIST_SIZE=4
+CONFIG_IDLE_THREAD_STACK_SIZE=256
+CONFIG_RT_USING_TIMER_SOFT=y
+CONFIG_RT_TIMER_THREAD_PRIO=4
+CONFIG_RT_TIMER_THREAD_STACK_SIZE=512
+
+#
+# kservice optimization
+#
+CONFIG_RT_KSERVICE_USING_STDLIB=y
+# CONFIG_RT_KSERVICE_USING_STDLIB_MEMORY is not set
+# CONFIG_RT_KSERVICE_USING_TINY_SIZE is not set
+# CONFIG_RT_USING_TINY_FFS is not set
+# CONFIG_RT_KPRINTF_USING_LONGLONG is not set
+CONFIG_RT_USING_DEBUG=y
+CONFIG_RT_DEBUGING_COLOR=y
+CONFIG_RT_DEBUGING_CONTEXT=y
+CONFIG_RT_DEBUGING_INIT=y
+# CONFIG_RT_DEBUGING_PAGE_LEAK is not set
+
+#
+# Inter-Thread communication
+#
+CONFIG_RT_USING_SEMAPHORE=y
+CONFIG_RT_USING_MUTEX=y
+CONFIG_RT_USING_EVENT=y
+CONFIG_RT_USING_MAILBOX=y
+CONFIG_RT_USING_MESSAGEQUEUE=y
+# CONFIG_RT_USING_MESSAGEQUEUE_PRIORITY is not set
+# CONFIG_RT_USING_SIGNALS is not set
+
+#
+# Memory Management
+#
+CONFIG_RT_PAGE_MAX_ORDER=11
+CONFIG_RT_USING_MEMPOOL=y
+CONFIG_RT_USING_SMALL_MEM=y
+# CONFIG_RT_USING_SLAB is not set
+# CONFIG_RT_USING_MEMHEAP is not set
+CONFIG_RT_USING_SMALL_MEM_AS_HEAP=y
+# CONFIG_RT_USING_MEMHEAP_AS_HEAP is not set
+# CONFIG_RT_USING_SLAB_AS_HEAP is not set
+# CONFIG_RT_USING_USERHEAP is not set
+# CONFIG_RT_USING_NOHEAP is not set
+# CONFIG_RT_USING_MEMTRACE is not set
+# CONFIG_RT_USING_HEAP_ISR is not set
+CONFIG_RT_USING_HEAP=y
+
+#
+# Kernel Device Object
+#
+CONFIG_RT_USING_DEVICE=y
+# CONFIG_RT_USING_DEVICE_OPS is not set
+# CONFIG_RT_USING_DM is not set
+# CONFIG_RT_USING_INTERRUPT_INFO is not set
+CONFIG_RT_USING_CONSOLE=y
+CONFIG_RT_CONSOLEBUF_SIZE=128
+CONFIG_RT_CONSOLE_DEVICE_NAME="uart0"
+CONFIG_RT_VER_NUM=0x50001
+# CONFIG_RT_USING_STDC_ATOMIC is not set
+CONFIG_RT_USING_CACHE=y
+CONFIG_RT_USING_HW_ATOMIC=y
+# CONFIG_ARCH_ARM_BOOTWITH_FLUSH_CACHE is not set
+# CONFIG_ARCH_CPU_STACK_GROWS_UPWARD is not set
+CONFIG_RT_USING_CPU_FFS=y
+CONFIG_ARCH_MM_MMU=y
+CONFIG_ARCH_ARM=y
+CONFIG_ARCH_ARM_MMU=y
+CONFIG_ARCH_ARM_CORTEX_A=y
+# CONFIG_RT_SMP_AUTO_BOOT is not set
+CONFIG_RT_USING_GIC_V2=y
+# CONFIG_RT_USING_GIC_V3 is not set
+CONFIG_ARCH_ARM_CORTEX_A9=y
+# CONFIG_ARCH_ARM_SECURE_MODE is not set
+# CONFIG_RT_BACKTRACE_FUNCTION_NAME is not set
+
+#
+# RT-Thread Components
+#
+CONFIG_RT_USING_COMPONENTS_INIT=y
+CONFIG_RT_USING_USER_MAIN=y
+CONFIG_RT_MAIN_THREAD_STACK_SIZE=2048
+CONFIG_RT_MAIN_THREAD_PRIORITY=10
+# CONFIG_RT_USING_LEGACY is not set
+CONFIG_RT_USING_MSH=y
+CONFIG_RT_USING_FINSH=y
+CONFIG_FINSH_USING_MSH=y
+CONFIG_FINSH_THREAD_NAME="tshell"
+CONFIG_FINSH_THREAD_PRIORITY=20
+CONFIG_FINSH_THREAD_STACK_SIZE=4096
+CONFIG_FINSH_USING_HISTORY=y
+CONFIG_FINSH_HISTORY_LINES=5
+CONFIG_FINSH_USING_SYMTAB=y
+CONFIG_FINSH_CMD_SIZE=80
+CONFIG_MSH_USING_BUILT_IN_COMMANDS=y
+CONFIG_FINSH_USING_DESCRIPTION=y
+# CONFIG_FINSH_ECHO_DISABLE_DEFAULT is not set
+# CONFIG_FINSH_USING_AUTH is not set
+CONFIG_FINSH_ARG_MAX=10
+
+#
+# DFS: device virtual file system
+#
+CONFIG_RT_USING_DFS=y
+CONFIG_DFS_USING_POSIX=y
+CONFIG_DFS_USING_WORKDIR=y
+# CONFIG_RT_USING_DFS_MNTTABLE is not set
+CONFIG_DFS_FD_MAX=16
+CONFIG_RT_USING_DFS_V1=y
+# CONFIG_RT_USING_DFS_V2 is not set
+CONFIG_DFS_FILESYSTEMS_MAX=4
+CONFIG_DFS_FILESYSTEM_TYPES_MAX=4
+# CONFIG_RT_USING_DFS_ELMFAT is not set
+CONFIG_RT_USING_DFS_DEVFS=y
+# CONFIG_RT_USING_DFS_ROMFS is not set
+# CONFIG_RT_USING_DFS_CROMFS is not set
+# CONFIG_RT_USING_DFS_RAMFS is not set
+# CONFIG_RT_USING_DFS_TMPFS is not set
+# CONFIG_RT_USING_DFS_MQUEUE is not set
+# CONFIG_RT_USING_FAL is not set
+
+#
+# Device Drivers
+#
+CONFIG_RT_USING_DEVICE_IPC=y
+CONFIG_RT_UNAMED_PIPE_NUMBER=64
+# CONFIG_RT_USING_SYSTEM_WORKQUEUE is not set
+CONFIG_RT_USING_SERIAL=y
+CONFIG_RT_USING_SERIAL_V1=y
+# CONFIG_RT_USING_SERIAL_V2 is not set
+CONFIG_RT_SERIAL_USING_DMA=y
+CONFIG_RT_SERIAL_RB_BUFSZ=64
+# CONFIG_RT_USING_CAN is not set
+# CONFIG_RT_USING_HWTIMER is not set
+# CONFIG_RT_USING_CPUTIME is not set
+# CONFIG_RT_USING_I2C is not set
+# CONFIG_RT_USING_PHY is not set
+CONFIG_RT_USING_PIN=y
+# CONFIG_RT_USING_ADC is not set
+# CONFIG_RT_USING_DAC is not set
+# CONFIG_RT_USING_NULL is not set
+# CONFIG_RT_USING_ZERO is not set
+# CONFIG_RT_USING_RANDOM is not set
+# CONFIG_RT_USING_PWM is not set
+# CONFIG_RT_USING_MTD_NOR is not set
+# CONFIG_RT_USING_MTD_NAND is not set
+# CONFIG_RT_USING_PM is not set
+# CONFIG_RT_USING_FDT is not set
+# CONFIG_RT_USING_RTC is not set
+# CONFIG_RT_USING_SDIO is not set
+# CONFIG_RT_USING_SPI is not set
+# CONFIG_RT_USING_WDT is not set
+# CONFIG_RT_USING_AUDIO is not set
+# CONFIG_RT_USING_SENSOR is not set
+# CONFIG_RT_USING_TOUCH is not set
+# CONFIG_RT_USING_LCD is not set
+# CONFIG_RT_USING_HWCRYPTO is not set
+# CONFIG_RT_USING_PULSE_ENCODER is not set
+# CONFIG_RT_USING_INPUT_CAPTURE is not set
+# CONFIG_RT_USING_DEV_BUS is not set
+# CONFIG_RT_USING_WIFI is not set
+# CONFIG_RT_USING_VIRTIO is not set
+
+#
+# Using USB
+#
+# CONFIG_RT_USING_USB is not set
+# CONFIG_RT_USING_USB_HOST is not set
+# CONFIG_RT_USING_USB_DEVICE is not set
+
+#
+# C/C++ and POSIX layer
+#
+CONFIG_RT_LIBC_DEFAULT_TIMEZONE=8
+
+#
+# POSIX (Portable Operating System Interface) layer
+#
+# CONFIG_RT_USING_POSIX_FS is not set
+# CONFIG_RT_USING_POSIX_DELAY is not set
+# CONFIG_RT_USING_POSIX_CLOCK is not set
+# CONFIG_RT_USING_POSIX_TIMER is not set
+# CONFIG_RT_USING_PTHREADS is not set
+# CONFIG_RT_USING_MODULE is not set
+
+#
+# Interprocess Communication (IPC)
+#
+# CONFIG_RT_USING_POSIX_PIPE is not set
+# CONFIG_RT_USING_POSIX_MESSAGE_QUEUE is not set
+# CONFIG_RT_USING_POSIX_MESSAGE_SEMAPHORE is not set
+
+#
+# Socket is in the 'Network' category
+#
+# CONFIG_RT_USING_CPLUSPLUS is not set
+
+#
+# Network
+#
+# CONFIG_RT_USING_SAL is not set
+# CONFIG_RT_USING_NETDEV is not set
+# CONFIG_RT_USING_LWIP is not set
+# CONFIG_RT_USING_AT is not set
+
+#
+# Utilities
+#
+# CONFIG_RT_USING_RYM is not set
+# CONFIG_RT_USING_ULOG is not set
+# CONFIG_RT_USING_UTEST is not set
+# CONFIG_RT_USING_VAR_EXPORT is not set
+# CONFIG_RT_USING_RESOURCE_ID is not set
+CONFIG_RT_USING_ADT=y
+CONFIG_RT_USING_ADT_AVL=y
+CONFIG_RT_USING_ADT_BITMAP=y
+CONFIG_RT_USING_ADT_HASHMAP=y
+CONFIG_RT_USING_ADT_REF=y
+# CONFIG_RT_USING_RT_LINK is not set
+# CONFIG_RT_USING_VBUS is not set
+# CONFIG_RT_USING_KTIME is not set
+
+#
+# RT-Thread Utestcases
+#
+# CONFIG_RT_USING_UTESTCASES is not set
+
+#
+# Hardware Drivers Config
+#
+
+#
+# On-chip Peripheral Drivers
+#
+CONFIG_BSP_USING_GPIO=y
+CONFIG_BSP_USING_UART=y
+CONFIG_BSP_USING_UART0=y
+# CONFIG_BSP_USING_UART1 is not set
+CONFIG_SOC_ZYNQ_7000=y
+CONFIG_RT_USING_FPU=y
+
+#
+# RT-Thread online packages
+#
+
+#
+# IoT - internet of things
+#
+# CONFIG_PKG_USING_LWIP is not set
+# CONFIG_PKG_USING_LORAWAN_DRIVER is not set
+# CONFIG_PKG_USING_PAHOMQTT is not set
+# CONFIG_PKG_USING_UMQTT is not set
+# CONFIG_PKG_USING_WEBCLIENT is not set
+# CONFIG_PKG_USING_WEBNET is not set
+# CONFIG_PKG_USING_MONGOOSE is not set
+# CONFIG_PKG_USING_MYMQTT is not set
+# CONFIG_PKG_USING_KAWAII_MQTT is not set
+# CONFIG_PKG_USING_BC28_MQTT is not set
+# CONFIG_PKG_USING_WEBTERMINAL is not set
+# CONFIG_PKG_USING_FREEMODBUS is not set
+# CONFIG_PKG_USING_NANOPB is not set
+
+#
+# Wi-Fi
+#
+
+#
+# Marvell WiFi
+#
+# CONFIG_PKG_USING_WLANMARVELL is not set
+
+#
+# Wiced WiFi
+#
+# CONFIG_PKG_USING_WLAN_WICED is not set
+# CONFIG_PKG_USING_RW007 is not set
+
+#
+# CYW43012 WiFi
+#
+# CONFIG_PKG_USING_WLAN_CYW43012 is not set
+# CONFIG_PKG_USING_COAP is not set
+# CONFIG_PKG_USING_NOPOLL is not set
+# CONFIG_PKG_USING_NETUTILS is not set
+# CONFIG_PKG_USING_CMUX is not set
+# CONFIG_PKG_USING_PPP_DEVICE is not set
+# CONFIG_PKG_USING_AT_DEVICE is not set
+# CONFIG_PKG_USING_ATSRV_SOCKET is not set
+# CONFIG_PKG_USING_WIZNET is not set
+# CONFIG_PKG_USING_ZB_COORDINATOR is not set
+
+#
+# IoT Cloud
+#
+# CONFIG_PKG_USING_ONENET is not set
+# CONFIG_PKG_USING_GAGENT_CLOUD is not set
+# CONFIG_PKG_USING_ALI_IOTKIT is not set
+# CONFIG_PKG_USING_AZURE is not set
+# CONFIG_PKG_USING_TENCENT_IOT_EXPLORER is not set
+# CONFIG_PKG_USING_JIOT-C-SDK is not set
+# CONFIG_PKG_USING_UCLOUD_IOT_SDK is not set
+# CONFIG_PKG_USING_JOYLINK is not set
+# CONFIG_PKG_USING_EZ_IOT_OS is not set
+# CONFIG_PKG_USING_IOTSHARP_SDK is not set
+# CONFIG_PKG_USING_NIMBLE is not set
+# CONFIG_PKG_USING_LLSYNC_SDK_ADAPTER is not set
+# CONFIG_PKG_USING_OTA_DOWNLOADER is not set
+# CONFIG_PKG_USING_IPMSG is not set
+# CONFIG_PKG_USING_LSSDP is not set
+# CONFIG_PKG_USING_AIRKISS_OPEN is not set
+# CONFIG_PKG_USING_LIBRWS is not set
+# CONFIG_PKG_USING_TCPSERVER is not set
+# CONFIG_PKG_USING_PROTOBUF_C is not set
+# CONFIG_PKG_USING_DLT645 is not set
+# CONFIG_PKG_USING_QXWZ is not set
+# CONFIG_PKG_USING_SMTP_CLIENT is not set
+# CONFIG_PKG_USING_ABUP_FOTA is not set
+# CONFIG_PKG_USING_LIBCURL2RTT is not set
+# CONFIG_PKG_USING_CAPNP is not set
+# CONFIG_PKG_USING_AGILE_TELNET is not set
+# CONFIG_PKG_USING_NMEALIB is not set
+# CONFIG_PKG_USING_PDULIB is not set
+# CONFIG_PKG_USING_BTSTACK is not set
+# CONFIG_PKG_USING_LORAWAN_ED_STACK is not set
+# CONFIG_PKG_USING_WAYZ_IOTKIT is not set
+# CONFIG_PKG_USING_MAVLINK is not set
+# CONFIG_PKG_USING_BSAL is not set
+# CONFIG_PKG_USING_AGILE_MODBUS is not set
+# CONFIG_PKG_USING_AGILE_FTP is not set
+# CONFIG_PKG_USING_EMBEDDEDPROTO is not set
+# CONFIG_PKG_USING_RT_LINK_HW is not set
+# CONFIG_PKG_USING_RYANMQTT is not set
+# CONFIG_PKG_USING_RYANW5500 is not set
+# CONFIG_PKG_USING_LORA_PKT_FWD is not set
+# CONFIG_PKG_USING_LORA_GW_DRIVER_LIB is not set
+# CONFIG_PKG_USING_LORA_PKT_SNIFFER is not set
+# CONFIG_PKG_USING_HM is not set
+# CONFIG_PKG_USING_SMALL_MODBUS is not set
+# CONFIG_PKG_USING_NET_SERVER is not set
+# CONFIG_PKG_USING_ZFTP is not set
+# CONFIG_PKG_USING_WOL is not set
+# CONFIG_PKG_USING_ZEPHYR_POLLING is not set
+
+#
+# security packages
+#
+# CONFIG_PKG_USING_MBEDTLS is not set
+# CONFIG_PKG_USING_LIBSODIUM is not set
+# CONFIG_PKG_USING_LIBHYDROGEN is not set
+# CONFIG_PKG_USING_TINYCRYPT is not set
+# CONFIG_PKG_USING_TFM is not set
+# CONFIG_PKG_USING_YD_CRYPTO is not set
+
+#
+# language packages
+#
+
+#
+# JSON: JavaScript Object Notation, a lightweight data-interchange format
+#
+# CONFIG_PKG_USING_CJSON is not set
+# CONFIG_PKG_USING_LJSON is not set
+# CONFIG_PKG_USING_RT_CJSON_TOOLS is not set
+# CONFIG_PKG_USING_RAPIDJSON is not set
+# CONFIG_PKG_USING_JSMN is not set
+# CONFIG_PKG_USING_AGILE_JSMN is not set
+# CONFIG_PKG_USING_PARSON is not set
+
+#
+# XML: Extensible Markup Language
+#
+# CONFIG_PKG_USING_SIMPLE_XML is not set
+# CONFIG_PKG_USING_EZXML is not set
+# CONFIG_PKG_USING_LUATOS_SOC is not set
+# CONFIG_PKG_USING_LUA is not set
+# CONFIG_PKG_USING_JERRYSCRIPT is not set
+# CONFIG_PKG_USING_MICROPYTHON is not set
+# CONFIG_PKG_USING_PIKASCRIPT is not set
+# CONFIG_PKG_USING_RTT_RUST is not set
+
+#
+# multimedia packages
+#
+
+#
+# LVGL: powerful and easy-to-use embedded GUI library
+#
+# CONFIG_PKG_USING_LVGL is not set
+# CONFIG_PKG_USING_LV_MUSIC_DEMO is not set
+# CONFIG_PKG_USING_GUI_GUIDER_DEMO is not set
+
+#
+# u8g2: a monochrome graphic library
+#
+# CONFIG_PKG_USING_U8G2_OFFICIAL is not set
+# CONFIG_PKG_USING_U8G2 is not set
+# CONFIG_PKG_USING_OPENMV is not set
+# CONFIG_PKG_USING_MUPDF is not set
+# CONFIG_PKG_USING_STEMWIN is not set
+# CONFIG_PKG_USING_WAVPLAYER is not set
+# CONFIG_PKG_USING_TJPGD is not set
+# CONFIG_PKG_USING_PDFGEN is not set
+# CONFIG_PKG_USING_HELIX is not set
+# CONFIG_PKG_USING_AZUREGUIX is not set
+# CONFIG_PKG_USING_TOUCHGFX2RTT is not set
+# CONFIG_PKG_USING_NUEMWIN is not set
+# CONFIG_PKG_USING_MP3PLAYER is not set
+# CONFIG_PKG_USING_TINYJPEG is not set
+# CONFIG_PKG_USING_UGUI is not set
+# CONFIG_PKG_USING_MCURSES is not set
+# CONFIG_PKG_USING_TERMBOX is not set
+# CONFIG_PKG_USING_VT100 is not set
+# CONFIG_PKG_USING_QRCODE is not set
+# CONFIG_PKG_USING_GUIENGINE is not set
+# CONFIG_PKG_USING_PERSIMMON is not set
+# CONFIG_PKG_USING_3GPP_AMRNB is not set
+
+#
+# tools packages
+#
+# CONFIG_PKG_USING_CMBACKTRACE is not set
+# CONFIG_PKG_USING_EASYFLASH is not set
+# CONFIG_PKG_USING_EASYLOGGER is not set
+# CONFIG_PKG_USING_SYSTEMVIEW is not set
+# CONFIG_PKG_USING_SEGGER_RTT is not set
+# CONFIG_PKG_USING_RTT_AUTO_EXE_CMD is not set
+# CONFIG_PKG_USING_RDB is not set
+# CONFIG_PKG_USING_ULOG_EASYFLASH is not set
+# CONFIG_PKG_USING_LOGMGR is not set
+# CONFIG_PKG_USING_ADBD is not set
+# CONFIG_PKG_USING_COREMARK is not set
+# CONFIG_PKG_USING_DHRYSTONE is not set
+# CONFIG_PKG_USING_MEMORYPERF is not set
+# CONFIG_PKG_USING_NR_MICRO_SHELL is not set
+# CONFIG_PKG_USING_CHINESE_FONT_LIBRARY is not set
+# CONFIG_PKG_USING_LUNAR_CALENDAR is not set
+# CONFIG_PKG_USING_BS8116A is not set
+# CONFIG_PKG_USING_GPS_RMC is not set
+# CONFIG_PKG_USING_URLENCODE is not set
+# CONFIG_PKG_USING_UMCN is not set
+# CONFIG_PKG_USING_LWRB2RTT is not set
+# CONFIG_PKG_USING_CPU_USAGE is not set
+# CONFIG_PKG_USING_GBK2UTF8 is not set
+# CONFIG_PKG_USING_VCONSOLE is not set
+# CONFIG_PKG_USING_KDB is not set
+# CONFIG_PKG_USING_WAMR is not set
+# CONFIG_PKG_USING_MICRO_XRCE_DDS_CLIENT is not set
+# CONFIG_PKG_USING_LWLOG is not set
+# CONFIG_PKG_USING_ANV_TRACE is not set
+# CONFIG_PKG_USING_ANV_MEMLEAK is not set
+# CONFIG_PKG_USING_ANV_TESTSUIT is not set
+# CONFIG_PKG_USING_ANV_BENCH is not set
+# CONFIG_PKG_USING_DEVMEM is not set
+# CONFIG_PKG_USING_REGEX is not set
+# CONFIG_PKG_USING_MEM_SANDBOX is not set
+# CONFIG_PKG_USING_SOLAR_TERMS is not set
+# CONFIG_PKG_USING_GAN_ZHI is not set
+# CONFIG_PKG_USING_FDT is not set
+# CONFIG_PKG_USING_CBOX is not set
+# CONFIG_PKG_USING_SNOWFLAKE is not set
+# CONFIG_PKG_USING_HASH_MATCH is not set
+# CONFIG_PKG_USING_ARMV7M_DWT_TOOL is not set
+# CONFIG_PKG_USING_VOFA_PLUS is not set
+# CONFIG_PKG_USING_ZDEBUG is not set
+
+#
+# system packages
+#
+
+#
+# enhanced kernel services
+#
+# CONFIG_PKG_USING_RT_MEMCPY_CM is not set
+# CONFIG_PKG_USING_RT_KPRINTF_THREADSAFE is not set
+# CONFIG_PKG_USING_RT_VSNPRINTF_FULL is not set
+
+#
+# acceleration: Assembly language or algorithmic acceleration packages
+#
+# CONFIG_PKG_USING_QFPLIB_M0_FULL is not set
+# CONFIG_PKG_USING_QFPLIB_M0_TINY is not set
+# CONFIG_PKG_USING_QFPLIB_M3 is not set
+
+#
+# CMSIS: ARM Cortex-M Microcontroller Software Interface Standard
+#
+# CONFIG_PKG_USING_CMSIS_5 is not set
+# CONFIG_PKG_USING_CMSIS_RTOS1 is not set
+# CONFIG_PKG_USING_CMSIS_RTOS2 is not set
+
+#
+# Micrium: Micrium software products porting for RT-Thread
+#
+# CONFIG_PKG_USING_UCOSIII_WRAPPER is not set
+# CONFIG_PKG_USING_UCOSII_WRAPPER is not set
+# CONFIG_PKG_USING_UC_CRC is not set
+# CONFIG_PKG_USING_UC_CLK is not set
+# CONFIG_PKG_USING_UC_COMMON is not set
+# CONFIG_PKG_USING_UC_MODBUS is not set
+# CONFIG_PKG_USING_FREERTOS_WRAPPER is not set
+# CONFIG_PKG_USING_LITEOS_SDK is not set
+# CONFIG_PKG_USING_CAIRO is not set
+# CONFIG_PKG_USING_PIXMAN is not set
+# CONFIG_PKG_USING_PARTITION is not set
+# CONFIG_PKG_USING_PERF_COUNTER is not set
+# CONFIG_PKG_USING_FLASHDB is not set
+# CONFIG_PKG_USING_SQLITE is not set
+# CONFIG_PKG_USING_RTI is not set
+# CONFIG_PKG_USING_DFS_YAFFS is not set
+# CONFIG_PKG_USING_LITTLEFS is not set
+# CONFIG_PKG_USING_DFS_JFFS2 is not set
+# CONFIG_PKG_USING_DFS_UFFS is not set
+# CONFIG_PKG_USING_LWEXT4 is not set
+# CONFIG_PKG_USING_THREAD_POOL is not set
+# CONFIG_PKG_USING_ROBOTS is not set
+# CONFIG_PKG_USING_EV is not set
+# CONFIG_PKG_USING_SYSWATCH is not set
+# CONFIG_PKG_USING_SYS_LOAD_MONITOR is not set
+# CONFIG_PKG_USING_PLCCORE is not set
+# CONFIG_PKG_USING_RAMDISK is not set
+# CONFIG_PKG_USING_MININI is not set
+# CONFIG_PKG_USING_QBOOT is not set
+# CONFIG_PKG_USING_PPOOL is not set
+# CONFIG_PKG_USING_OPENAMP is not set
+# CONFIG_PKG_USING_LPM is not set
+# CONFIG_PKG_USING_TLSF is not set
+# CONFIG_PKG_USING_EVENT_RECORDER is not set
+# CONFIG_PKG_USING_ARM_2D is not set
+# CONFIG_PKG_USING_MCUBOOT is not set
+# CONFIG_PKG_USING_TINYUSB is not set
+# CONFIG_PKG_USING_CHERRYUSB is not set
+# CONFIG_PKG_USING_KMULTI_RTIMER is not set
+# CONFIG_PKG_USING_TFDB is not set
+# CONFIG_PKG_USING_QPC is not set
+# CONFIG_PKG_USING_AGILE_UPGRADE is not set
+# CONFIG_PKG_USING_FLASH_BLOB is not set
+# CONFIG_PKG_USING_MLIBC is not set
+# CONFIG_PKG_USING_TASK_MSG_BUS is not set
+
+#
+# peripheral libraries and drivers
+#
+
+#
+# sensors drivers
+#
+# CONFIG_PKG_USING_LSM6DSM is not set
+# CONFIG_PKG_USING_LSM6DSL is not set
+# CONFIG_PKG_USING_LPS22HB is not set
+# CONFIG_PKG_USING_HTS221 is not set
+# CONFIG_PKG_USING_LSM303AGR is not set
+# CONFIG_PKG_USING_BME280 is not set
+# CONFIG_PKG_USING_BME680 is not set
+# CONFIG_PKG_USING_BMA400 is not set
+# CONFIG_PKG_USING_BMI160_BMX160 is not set
+# CONFIG_PKG_USING_SPL0601 is not set
+# CONFIG_PKG_USING_MS5805 is not set
+# CONFIG_PKG_USING_DA270 is not set
+# CONFIG_PKG_USING_DF220 is not set
+# CONFIG_PKG_USING_HSHCAL001 is not set
+# CONFIG_PKG_USING_BH1750 is not set
+# CONFIG_PKG_USING_MPU6XXX is not set
+# CONFIG_PKG_USING_AHT10 is not set
+# CONFIG_PKG_USING_AP3216C is not set
+# CONFIG_PKG_USING_TSL4531 is not set
+# CONFIG_PKG_USING_DS18B20 is not set
+# CONFIG_PKG_USING_DHT11 is not set
+# CONFIG_PKG_USING_DHTXX is not set
+# CONFIG_PKG_USING_GY271 is not set
+# CONFIG_PKG_USING_GP2Y10 is not set
+# CONFIG_PKG_USING_SGP30 is not set
+# CONFIG_PKG_USING_HDC1000 is not set
+# CONFIG_PKG_USING_BMP180 is not set
+# CONFIG_PKG_USING_BMP280 is not set
+# CONFIG_PKG_USING_SHTC1 is not set
+# CONFIG_PKG_USING_BMI088 is not set
+# CONFIG_PKG_USING_HMC5883 is not set
+# CONFIG_PKG_USING_MAX6675 is not set
+# CONFIG_PKG_USING_TMP1075 is not set
+# CONFIG_PKG_USING_SR04 is not set
+# CONFIG_PKG_USING_CCS811 is not set
+# CONFIG_PKG_USING_PMSXX is not set
+# CONFIG_PKG_USING_RT3020 is not set
+# CONFIG_PKG_USING_MLX90632 is not set
+# CONFIG_PKG_USING_MLX90393 is not set
+# CONFIG_PKG_USING_MLX90392 is not set
+# CONFIG_PKG_USING_MLX90397 is not set
+# CONFIG_PKG_USING_MS5611 is not set
+# CONFIG_PKG_USING_MAX31865 is not set
+# CONFIG_PKG_USING_VL53L0X is not set
+# CONFIG_PKG_USING_INA260 is not set
+# CONFIG_PKG_USING_MAX30102 is not set
+# CONFIG_PKG_USING_INA226 is not set
+# CONFIG_PKG_USING_LIS2DH12 is not set
+# CONFIG_PKG_USING_HS300X is not set
+# CONFIG_PKG_USING_ZMOD4410 is not set
+# CONFIG_PKG_USING_ISL29035 is not set
+# CONFIG_PKG_USING_MMC3680KJ is not set
+# CONFIG_PKG_USING_QMP6989 is not set
+# CONFIG_PKG_USING_BALANCE is not set
+# CONFIG_PKG_USING_SHT2X is not set
+# CONFIG_PKG_USING_SHT3X is not set
+# CONFIG_PKG_USING_SHT4X is not set
+# CONFIG_PKG_USING_AD7746 is not set
+# CONFIG_PKG_USING_ADT74XX is not set
+# CONFIG_PKG_USING_MAX17048 is not set
+# CONFIG_PKG_USING_AS7341 is not set
+# CONFIG_PKG_USING_CW2015 is not set
+# CONFIG_PKG_USING_ICM20608 is not set
+# CONFIG_PKG_USING_PAJ7620 is not set
+# CONFIG_PKG_USING_STHS34PF80 is not set
+
+#
+# touch drivers
+#
+# CONFIG_PKG_USING_GT9147 is not set
+# CONFIG_PKG_USING_GT1151 is not set
+# CONFIG_PKG_USING_GT917S is not set
+# CONFIG_PKG_USING_GT911 is not set
+# CONFIG_PKG_USING_FT6206 is not set
+# CONFIG_PKG_USING_FT5426 is not set
+# CONFIG_PKG_USING_FT6236 is not set
+# CONFIG_PKG_USING_XPT2046_TOUCH is not set
+# CONFIG_PKG_USING_CST816X is not set
+# CONFIG_PKG_USING_REALTEK_AMEBA is not set
+# CONFIG_PKG_USING_STM32_SDIO is not set
+# CONFIG_PKG_USING_ESP_IDF is not set
+# CONFIG_PKG_USING_BUTTON is not set
+# CONFIG_PKG_USING_PCF8574 is not set
+# CONFIG_PKG_USING_SX12XX is not set
+# CONFIG_PKG_USING_SIGNAL_LED is not set
+# CONFIG_PKG_USING_LEDBLINK is not set
+# CONFIG_PKG_USING_LITTLED is not set
+# CONFIG_PKG_USING_LKDGUI is not set
+# CONFIG_PKG_USING_NRF5X_SDK is not set
+# CONFIG_PKG_USING_NRFX is not set
+
+#
+# Kendryte SDK
+#
+# CONFIG_PKG_USING_K210_SDK is not set
+# CONFIG_PKG_USING_KENDRYTE_SDK is not set
+# CONFIG_PKG_USING_INFRARED is not set
+# CONFIG_PKG_USING_MULTI_INFRARED is not set
+# CONFIG_PKG_USING_AGILE_BUTTON is not set
+# CONFIG_PKG_USING_AGILE_LED is not set
+# CONFIG_PKG_USING_AT24CXX is not set
+# CONFIG_PKG_USING_MOTIONDRIVER2RTT is not set
+# CONFIG_PKG_USING_PCA9685 is not set
+# CONFIG_PKG_USING_ILI9341 is not set
+# CONFIG_PKG_USING_I2C_TOOLS is not set
+# CONFIG_PKG_USING_NRF24L01 is not set
+# CONFIG_PKG_USING_RPLIDAR is not set
+# CONFIG_PKG_USING_AS608 is not set
+# CONFIG_PKG_USING_RC522 is not set
+# CONFIG_PKG_USING_WS2812B is not set
+# CONFIG_PKG_USING_EMBARC_BSP is not set
+# CONFIG_PKG_USING_EXTERN_RTC_DRIVERS is not set
+# CONFIG_PKG_USING_MULTI_RTIMER is not set
+# CONFIG_PKG_USING_MAX7219 is not set
+# CONFIG_PKG_USING_BEEP is not set
+# CONFIG_PKG_USING_EASYBLINK is not set
+# CONFIG_PKG_USING_PMS_SERIES is not set
+# CONFIG_PKG_USING_CAN_YMODEM is not set
+# CONFIG_PKG_USING_LORA_RADIO_DRIVER is not set
+# CONFIG_PKG_USING_QLED is not set
+# CONFIG_PKG_USING_AGILE_CONSOLE is not set
+# CONFIG_PKG_USING_LD3320 is not set
+# CONFIG_PKG_USING_WK2124 is not set
+# CONFIG_PKG_USING_LY68L6400 is not set
+# CONFIG_PKG_USING_DM9051 is not set
+# CONFIG_PKG_USING_SSD1306 is not set
+# CONFIG_PKG_USING_QKEY is not set
+# CONFIG_PKG_USING_RS485 is not set
+# CONFIG_PKG_USING_RS232 is not set
+# CONFIG_PKG_USING_NES is not set
+# CONFIG_PKG_USING_VIRTUAL_SENSOR is not set
+# CONFIG_PKG_USING_VDEVICE is not set
+# CONFIG_PKG_USING_SGM706 is not set
+# CONFIG_PKG_USING_STM32WB55_SDK is not set
+# CONFIG_PKG_USING_RDA58XX is not set
+# CONFIG_PKG_USING_LIBNFC is not set
+# CONFIG_PKG_USING_MFOC is not set
+# CONFIG_PKG_USING_TMC51XX is not set
+# CONFIG_PKG_USING_TCA9534 is not set
+# CONFIG_PKG_USING_KOBUKI is not set
+# CONFIG_PKG_USING_ROSSERIAL is not set
+# CONFIG_PKG_USING_MICRO_ROS is not set
+# CONFIG_PKG_USING_MCP23008 is not set
+# CONFIG_PKG_USING_BLUETRUM_SDK is not set
+# CONFIG_PKG_USING_MISAKA_AT24CXX is not set
+# CONFIG_PKG_USING_MISAKA_RGB_BLING is not set
+# CONFIG_PKG_USING_LORA_MODEM_DRIVER is not set
+# CONFIG_PKG_USING_SOFT_SERIAL is not set
+# CONFIG_PKG_USING_MB85RS16 is not set
+# CONFIG_PKG_USING_RFM300 is not set
+# CONFIG_PKG_USING_IO_INPUT_FILTER is not set
+# CONFIG_PKG_USING_RASPBERRYPI_PICO_SDK is not set
+# CONFIG_PKG_USING_LRF_NV7LIDAR is not set
+# CONFIG_PKG_USING_AIP650 is not set
+# CONFIG_PKG_USING_FINGERPRINT is not set
+# CONFIG_PKG_USING_BT_ECB02C is not set
+# CONFIG_PKG_USING_UAT is not set
+# CONFIG_PKG_USING_ST7789 is not set
+# CONFIG_PKG_USING_SPI_TOOLS is not set
+
+#
+# AI packages
+#
+# CONFIG_PKG_USING_LIBANN is not set
+# CONFIG_PKG_USING_NNOM is not set
+# CONFIG_PKG_USING_ONNX_BACKEND is not set
+# CONFIG_PKG_USING_ONNX_PARSER is not set
+# CONFIG_PKG_USING_TENSORFLOWLITEMICRO is not set
+# CONFIG_PKG_USING_ELAPACK is not set
+# CONFIG_PKG_USING_ULAPACK is not set
+# CONFIG_PKG_USING_QUEST is not set
+# CONFIG_PKG_USING_NAXOS is not set
+
+#
+# Signal Processing and Control Algorithm Packages
+#
+# CONFIG_PKG_USING_FIRE_PID_CURVE is not set
+# CONFIG_PKG_USING_QPID is not set
+# CONFIG_PKG_USING_UKAL is not set
+# CONFIG_PKG_USING_DIGITALCTRL is not set
+# CONFIG_PKG_USING_KISSFFT is not set
+# CONFIG_PKG_USING_CMSIS_DSP is not set
+
+#
+# miscellaneous packages
+#
+
+#
+# project laboratory
+#
+
+#
+# samples: kernel and components samples
+#
+# CONFIG_PKG_USING_KERNEL_SAMPLES is not set
+# CONFIG_PKG_USING_FILESYSTEM_SAMPLES is not set
+# CONFIG_PKG_USING_NETWORK_SAMPLES is not set
+# CONFIG_PKG_USING_PERIPHERAL_SAMPLES is not set
+
+#
+# entertainment: terminal games and other interesting software packages
+#
+# CONFIG_PKG_USING_CMATRIX is not set
+# CONFIG_PKG_USING_SL is not set
+# CONFIG_PKG_USING_CAL is not set
+# CONFIG_PKG_USING_ACLOCK is not set
+# CONFIG_PKG_USING_THREES is not set
+# CONFIG_PKG_USING_2048 is not set
+# CONFIG_PKG_USING_SNAKE is not set
+# CONFIG_PKG_USING_TETRIS is not set
+# CONFIG_PKG_USING_DONUT is not set
+# CONFIG_PKG_USING_COWSAY is not set
+# CONFIG_PKG_USING_MORSE is not set
+# CONFIG_PKG_USING_LIBCSV is not set
+# CONFIG_PKG_USING_OPTPARSE is not set
+# CONFIG_PKG_USING_FASTLZ is not set
+# CONFIG_PKG_USING_MINILZO is not set
+# CONFIG_PKG_USING_QUICKLZ is not set
+# CONFIG_PKG_USING_LZMA is not set
+# CONFIG_PKG_USING_MULTIBUTTON is not set
+# CONFIG_PKG_USING_FLEXIBLE_BUTTON is not set
+# CONFIG_PKG_USING_CANFESTIVAL is not set
+# CONFIG_PKG_USING_ZLIB is not set
+# CONFIG_PKG_USING_MINIZIP is not set
+# CONFIG_PKG_USING_HEATSHRINK is not set
+# CONFIG_PKG_USING_DSTR is not set
+# CONFIG_PKG_USING_TINYFRAME is not set
+# CONFIG_PKG_USING_KENDRYTE_DEMO is not set
+# CONFIG_PKG_USING_UPACKER is not set
+# CONFIG_PKG_USING_UPARAM is not set
+# CONFIG_PKG_USING_HELLO is not set
+# CONFIG_PKG_USING_VI is not set
+# CONFIG_PKG_USING_KI is not set
+# CONFIG_PKG_USING_ARMv7M_DWT is not set
+# CONFIG_PKG_USING_CRCLIB is not set
+# CONFIG_PKG_USING_LWGPS is not set
+# CONFIG_PKG_USING_STATE_MACHINE is not set
+# CONFIG_PKG_USING_DESIGN_PATTERN is not set
+# CONFIG_PKG_USING_CONTROLLER is not set
+# CONFIG_PKG_USING_PHASE_LOCKED_LOOP is not set
+# CONFIG_PKG_USING_MFBD is not set
+# CONFIG_PKG_USING_SLCAN2RTT is not set
+# CONFIG_PKG_USING_SOEM is not set
+# CONFIG_PKG_USING_QPARAM is not set
+# CONFIG_PKG_USING_CorevMCU_CLI is not set
+
+#
+# Arduino libraries
+#
+# CONFIG_PKG_USING_RTDUINO is not set
+
+#
+# Projects and Demos
+#
+# CONFIG_PKG_USING_ARDUINO_MSGQ_C_CPP_DEMO is not set
+# CONFIG_PKG_USING_ARDUINO_ULTRASOUND_RADAR is not set
+# CONFIG_PKG_USING_ARDUINO_SENSOR_KIT is not set
+# CONFIG_PKG_USING_ARDUINO_MATLAB_SUPPORT is not set
+
+#
+# Sensors
+#
+# CONFIG_PKG_USING_ARDUINO_SENSOR_DEVICE_DRIVERS is not set
+# CONFIG_PKG_USING_ARDUINO_CAPACITIVESENSOR is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_ADXL375 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_VL53L0X is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_VL53L1X is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SENSOR is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_VL6180X is not set
+# CONFIG_PKG_USING_ADAFRUIT_MAX31855 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MAX31865 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MAX31856 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MAX6675 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MLX90614 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LSM9DS1 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_AHTX0 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LSM9DS0 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BMP280 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_ADT7410 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BMP085 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BME680 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MCP9808 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MCP4728 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_INA219 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LTR390 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_ADXL345 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_DHT is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MCP9600 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LSM6DS is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BNO055 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MAX1704X is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MMC56X3 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MLX90393 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MLX90395 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_ICM20X is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_DPS310 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_HTS221 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SHT4X is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SHT31 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_ADXL343 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BME280 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_AS726X is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_AMG88XX is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_AM2320 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_AM2315 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LTR329_LTR303 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BMP085_UNIFIED is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BMP183 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BMP183_UNIFIED is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BMP3XX is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MS8607 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LIS3MDL is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MLX90640 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MMA8451 is not set
+# CONFIG_PKG_USING_ADAFRUIT_MSA301 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MPL115A2 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BNO08X is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BNO08X_RVC is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LIS2MDL is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LSM303DLH_MAG is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LC709203F is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_CAP1188 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_CCS811 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_NAU7802 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LIS331 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LPS2X is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LPS35HW is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LSM303_ACCEL is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_LIS3DH is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_PCF8591 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MPL3115A2 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MPR121 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MPRLS is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MPU6050 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_PCT2075 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_PM25AQI is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_EMC2101 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_FXAS21002C is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SCD30 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_FXOS8700 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_HMC5883_UNIFIED is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SGP30 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_TMP006 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_TLA202X is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_TCS34725 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SI7021 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SI1145 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SGP40 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SHTC3 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_HDC1000 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_HTU21DF is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_AS7341 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_HTU31D is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SENSORLAB is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_INA260 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_TMP007_LIBRARY is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_L3GD20 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_TMP117 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_TSC2007 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_TSL2561 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_TSL2591_LIBRARY is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_VCNL4040 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_VEML6070 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_VEML6075 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_VEML7700 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_LIS3DHTR is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_DHT is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_ADXL335 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_ADXL345 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_BME280 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_BMP280 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_H3LIS331DL is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_MMA7660 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_TSL2561 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_PAJ7620 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_VL53L0X is not set
+# CONFIG_PKG_USING_SEEED_ITG3200 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_SHT31 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_HP20X is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_DRV2605L is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_BBM150 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_HMC5883L is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_LSM303DLH is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_TCS3414CS is not set
+# CONFIG_PKG_USING_SEEED_MP503 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_BMP085 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_HIGHTEMP is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_VEML6070 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_SI1145 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_SHT35 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_AT42QT1070 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_LSM6DS3 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_HDC1000 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_HM3301 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_MCP9600 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_LTC2941 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_LDC1612 is not set
+
+#
+# Display
+#
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_GFX_LIBRARY is not set
+# CONFIG_PKG_USING_ARDUINO_U8G2 is not set
+# CONFIG_PKG_USING_ARDUINO_TFT_ESPI is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_ST7735 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SSD1306 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_ILI9341 is not set
+# CONFIG_PKG_USING_SEEED_TM1637 is not set
+
+#
+# Timing
+#
+# CONFIG_PKG_USING_ARDUINO_RTCLIB is not set
+# CONFIG_PKG_USING_ARDUINO_MSTIMER2 is not set
+# CONFIG_PKG_USING_ARDUINO_TICKER is not set
+# CONFIG_PKG_USING_ARDUINO_TASKSCHEDULER is not set
+
+#
+# Data Processing
+#
+# CONFIG_PKG_USING_ARDUINO_KALMANFILTER is not set
+# CONFIG_PKG_USING_ARDUINO_ARDUINOJSON is not set
+
+#
+# Data Storage
+#
+
+#
+# Communication
+#
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_PN532 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SI4713 is not set
+
+#
+# Device Control
+#
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_PCF8574 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_PCA9685 is not set
+# CONFIG_PKG_USING_ARDUINO_SEEED_PCF85063TP is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_TPA2016 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_DRV2605 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_DS1841 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_DS3502 is not set
+
+#
+# Other
+#
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MFRC630 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_SI5351 is not set
+
+#
+# Signal IO
+#
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BUSIO is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_TCA8418 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MCP23017 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_ADS1X15 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_AW9523 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MCP3008 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_MCP4725 is not set
+# CONFIG_PKG_USING_ARDUINO_ADAFRUIT_BD3491FS is not set
+
+#
+# Uncategorized
+#

bsp/zynq/zynq7000/Kconfig

@@ -0,0 +1,37 @@
+mainmenu "RT-Thread Project Configuration"
+
+config BSP_DIR
+    string
+    option env="BSP_ROOT"
+    default "."
+
+config RTT_DIR
+    string
+    option env="RTT_ROOT"
+    default "../../.."
+
+config PKGS_DIR
+    string
+    option env="PKGS_ROOT"
+    default "packages"
+
+source "$RTT_DIR/Kconfig"
+source "drivers/Kconfig"
+
+config SOC_ZYNQ_7000
+    bool
+    select ARCH_ARM_CORTEX_A9
+    select RT_USING_COMPONENTS_INIT
+    select RT_USING_USER_MAIN
+    select RT_USING_GIC_V2
+    default y
+
+config RT_USING_CACHE
+    bool
+    default y
+
+config RT_USING_FPU
+    bool
+    default y
+
+source "$PKGS_DIR/Kconfig"

bsp/zynq/zynq7000/README.md

@@ -0,0 +1,125 @@
+# 正点原子启明星开发板 BSP 说明
+
+## 简介
+
+本文档是为 正点原子启明星开发板提供的 BSP (板级支持包) 说明。
+
+主要内容如下：
+
+- 开发板资源介绍
+- 开发流程说明
+
+## 开发板介绍
+
+正点原子开发的基于 zynq7000 生成的开发板, 注: 理论上也可以适用于其它 zynq7000的开发板.
+
+![board](figures/board.jpg)
+
+开发板更多详细信息请参考[官方文档](http://www.openedv.com/docs/boards/fpga/zdyz_qimxing(V2).html)。
+
+## 外设支持
+
+本 BSP 目前对外设的支持情况如下：
+
+| **核心**      | **支持情况** | **备注**                              |
+| :----------------- | :----------: | :------------------------------------- |
+| cortex-a9   |     支持     | 运行系统的为cortex-a9核的CPU0 |
+| **板载外设**      | **支持情况** | **备注**                              |
+| 无 |          |  |
+| **片上外设**      | **支持情况** | **备注**                              |
+| GPIO              |     支持     |  |
+| UART              |     支持     | UART0,  UART1                           |
+| SPI FLASH         |     支持     |  |
+| EMMC / SDIO | 支持 | |
+| CAN | 即将支持 | |
+
+## 使用说明
+
+本 bsp 驱动基于之前的 zynq7000 bsp 的基础上，除了定时器仍然沿用之前的寄存器写法外，其余驱动均基于 vivado sdk 2017.4 生成的驱动库开发。具体开发使用流程如下:
+
+### 1. 创建 vivado 工程 & pl 部分开发
+
+使用 vivado 创建工程, 完成 pl 部分开发, 此部分与 rtt 软件开发无关,
+故省略具体说明. 注意 zynq ps 部分必须启用 `MIO`, `UART0` 和 `Quad SPI FLASH`.
+
+### 2. 启动 sdk 生成 bsp 和 fsbl
+
+完成第一步后, 导出硬件到 sdk, 然后启动 sdk, 创建 fsbl 工程
+
+![step2](figures/step_2.png)
+![step3](figures/step_3.png)
+
+由于后续即将添加的复杂驱动依赖于usleep.c 的接口函数, 故需要对 sdk
+中的 `bsp\ps7_cortexa9_0\libsrc\standalone_v6_5\src\usleep.c` 做如下修改:
+
+```DIFF
+@@ -63,6 +63,15 @@
+ /* Global Timer is always clocked at half of the CPU frequency */
+ #define COUNTS_PER_USECOND  (XPAR_CPU_CORTEXA9_CORE_CLOCK_FREQ_HZ / (2U*1000000U))
+
++typedef void (*usleep_hook_t) (unsigned long useconds);
++
++static usleep_hook_t usleep_hook;
++
++void zynq_set_usleep_hook(usleep_hook_t hook)
++{
++	usleep_hook = hook;
++}
++
+ /*****************************************************************************/
+ /**
+ *
+@@ -78,6 +87,12 @@
+ ****************************************************************************/
+ int usleep(unsigned long useconds)
+ {
++	if (usleep_hook)
++	{
++		usleep_hook(useconds);
++		return 0;
++	}
++
+ 	XTime tEnd, tCur;
+
+ 	XTime_GetTime(&tCur);
+
+```
+
+修改完成后保存文件，等待sdk 自动完成编译.
+
+### 3. 拷贝 sdk 下的 bsp, 完成 app 编译
+
+拷贝 sdk bsp 文件夹下的 `include` 和 `lib` 文件夹到 [bsp](bsp) 文件夹下
+
+![step4](figures/step_4.png)
+
+然后 scons 编译app, 得到 `rtthread-zynq7000.elf`
+
+### 4. 调试运行
+
+#### 方式1: sdk 调试运行
+
+1. 点击 SDK `Run` -> `Debug Configurations...`
+![step5](figures/step_5.png)
+
+2. 右键 new 创建新的 debug
+![stp6](figures/step_6.png)
+
+3. 配置 debug, 选择 app 所在路径
+![step7](figures/step_7.png)
+![step8](figures/step_8.png)
+
+4. 随后点击 debug 就可以运行了.效果如下图所示:
+![step9](figures/step_9.png)
+![step9_1](figures/step_9_1.png)
+
+#### 方式2: 生成 BOOT.BIN 拷贝到 sd 卡运行
+
+参见 vivado bootgen 使用方法，将 app 换成
+scons 编译生成的 `rtthread-zynq7000.elf` 即可
+
+## 联系人信息
+
+维护人:
+
+- [a1012112796](https://github.com/a1012112796)

bsp/zynq/zynq7000/SConscript

@@ -0,0 +1,15 @@
+# for module compiling
+import os
+Import('RTT_ROOT')
+from building import *
+
+cwd     = GetCurrentDir()
+objs = []
+list = os.listdir(cwd)
+
+for d in list:
+    path = os.path.join(cwd, d)
+    if os.path.isfile(os.path.join(path, 'SConscript')):
+        objs = objs + SConscript(os.path.join(d, 'SConscript'))
+
+Return('objs')

bsp/zynq/zynq7000/SConstruct

@@ -0,0 +1,40 @@
+import os
+import sys
+import rtconfig
+
+if os.getenv('RTT_ROOT'):
+    RTT_ROOT = os.getenv('RTT_ROOT')
+else:
+    RTT_ROOT = os.path.normpath(os.getcwd() + '/../../..')
+
+sys.path = sys.path + [os.path.join(RTT_ROOT, 'tools')]
+
+try:
+    from building import *
+except:
+    print('Cannot found RT-Thread root directory, please check RTT_TOOLS')
+    print(RTT_ROOT)
+    exit(-1)
+
+TARGET = 'rtthread-zynq7000.' + rtconfig.TARGET_EXT
+
+DefaultEnvironment(tools=[])
+env = Environment(tools = ['mingw'],
+        AS = rtconfig.AS, ASFLAGS = rtconfig.AFLAGS,
+        CC = rtconfig.CC, CCFLAGS = rtconfig.CFLAGS,
+        CXX = rtconfig.CXX, CXXFLAGS = rtconfig.CXXFLAGS,
+        AR = rtconfig.AR, ARFLAGS = '-rc',
+        LINK = rtconfig.LINK, LINKFLAGS = rtconfig.LFLAGS)
+env.PrependENVPath('PATH', rtconfig.EXEC_PATH)
+
+Export('RTT_ROOT')
+Export('rtconfig')
+
+# prepare building environment
+objs = PrepareBuilding(env, RTT_ROOT)
+
+# if the linker script changed, relink the target
+Depends(TARGET, rtconfig.LINK_SCRIPT)
+
+# make a building
+DoBuilding(TARGET, objs)

bsp/zynq/zynq7000/Xilinx.spec

@@ -0,0 +1,2 @@
+*startfile:
+crti%O%s crtbegin%O%s

bsp/zynq/zynq7000/applications/SConscript

@@ -0,0 +1,14 @@
+Import('RTT_ROOT')
+Import('rtconfig')
+from building import *
+
+cwd = GetCurrentDir()
+CPPPATH = [cwd + '/..']
+
+src = Split('''
+app.c
+''')
+
+group = DefineGroup('Applications', src, depend = [''], CPPPATH = CPPPATH)
+
+Return('group')

bsp/zynq/zynq7000/applications/app.c

@@ -0,0 +1,18 @@
+#include "rtthread.h"
+#include "rtdevice.h"
+
+#define LED_PIN 0
+
+int main(void)
+{
+    rt_pin_mode(LED_PIN, PIN_MODE_OUTPUT);
+    rt_uint8_t out = 0;
+
+    while(1)
+    {
+        rt_thread_mdelay(500);
+        rt_pin_write(LED_PIN, out);
+        out = (out + 1) % 2;
+    }
+    return 0;
+}

bsp/zynq/zynq7000/bootgen/.gitignore

@@ -0,0 +1 @@
+*.bit

bsp/zynq/zynq7000/bootgen/build.bat

@@ -0,0 +1 @@
+.\bootgen.exe -image output.bif -o BOOT.BIN -w on

bsp/zynq/zynq7000/bootgen/output.bif

@@ -0,0 +1,6 @@
+//arch = zynq; split = false; format = BIN
+the_ROM_image:
+{
+	[bootloader]fsbl.elf
+	..\rtthread-zynq7000.elf
+}

bsp/zynq/zynq7000/bsp/.gitignore

@@ -0,0 +1,2 @@
+/lib
+/include

bsp/zynq/zynq7000/bsp/SConscript

@@ -0,0 +1,15 @@
+
+from building import *
+
+cwd     = GetCurrentDir()
+CPPPATH = [cwd + '/include',]
+LIBS    = ['libxil',]
+LIBPATH = [cwd + '/lib']
+
+group = DefineGroup('zynq_hal', [],
+                    depend = [],
+                    CPPPATH = CPPPATH,
+                    LIBS = LIBS,
+                    LIBPATH = LIBPATH)
+
+Return('group')

bsp/zynq/zynq7000/drivers/Kconfig

@@ -0,0 +1,43 @@
+menu "Hardware Drivers Config"
+
+menu "On-chip Peripheral Drivers"
+    config BSP_USING_GPIO
+        bool "Enable zynq MIO"
+        select RT_USING_PIN
+        default y
+
+    menuconfig BSP_USING_UART
+        bool "Enable UART"
+        default y
+        select RT_USING_SERIAL
+        if BSP_USING_UART
+            config BSP_USING_UART0
+                bool "Enable UART0"
+                default y
+
+            config BSP_USING_UART1
+                bool "Enable UART1"
+                default n
+        endif
+
+    config BSP_USING_SPIFLASH
+        bool "Enable spi flash"
+        select RT_USING_FAL
+        default n
+
+    menuconfig BSP_USING_SDIO
+        bool "Enable sdio (emmc)"
+        default n
+
+        if BSP_USING_SDIO
+            config BSP_USING_SDIO0
+                bool "Enable sdio0"
+                default n
+
+            config BSP_USING_SDIO1
+                bool "Enable sdio1"
+                default n
+        endif
+endmenu
+
+endmenu

bsp/zynq/zynq7000/drivers/SConscript

@@ -0,0 +1,22 @@
+from building import *
+
+cwd = GetCurrentDir()
+src	= Glob('*.c')
+
+if GetDepend('BSP_USING_UART') == False:
+    src_need_remove = ['drv_uart.c'] # need remove file list.
+    SrcRemove(src, src_need_remove)
+
+if GetDepend('BSP_USING_SPIFLASH') == False:
+    src_need_remove = ['drv_spiflash.c'] # need remove file list.
+    SrcRemove(src, src_need_remove)
+
+if GetDepend('BSP_USING_SDIO') == False:
+    src_need_remove = ['drv_emmc.c'] # need remove file list.
+    SrcRemove(src, src_need_remove)
+
+CPPPATH = [cwd]
+
+group = DefineGroup('Drivers', src, depend = [''], CPPPATH = CPPPATH)
+
+Return('group')

bsp/zynq/zynq7000/drivers/board.c

@@ -0,0 +1,130 @@
+#include <rthw.h>
+#include <rtthread.h>
+#include "xil_assert.h"
+#include "rtdevice.h"
+#include "drv_gpio.h"
+#include <mmu.h>
+
+extern rt_uint32_t __text_start;
+
+struct mem_desc platform_mem_desc[] = {
+    /* no access to the memory below .text */
+    /* 521Mb cached DDR memory */
+    {(rt_uint32_t)&__text_start, 0x3F600000-1, (rt_uint32_t)&__text_start, NORMAL_MEM},
+    /* PL region */
+    {0x40000000, 0xBFFFFFFF, 0x40000000, DEVICE_MEM},
+    /* IOP registers */
+    {0xE0000000, 0xE02FFFFF, 0xE0000000, DEVICE_MEM},
+    /* SLCR, PS and CPU private registers, note we map more memory space as the
+     * entry is 1MB in size. */
+    {0xF8000000, 0xFFFFFFFF, 0xF8000000, DEVICE_MEM},
+};
+
+const rt_uint32_t platform_mem_desc_size = sizeof(platform_mem_desc)/sizeof(platform_mem_desc[0]);
+
+void idle_wfi(void)
+{
+    asm volatile ("wfi");
+}
+
+static void rt_xil_assert_callback(const char8 *File, s32 Line)
+{
+    rt_kprintf("Xil_AssertCallback: %s, %d\n", File, Line);
+    RT_ASSERT(0);
+}
+
+typedef void (*usleep_hook_t) (unsigned long useconds);
+
+// note: should edit usleep.c in bsp to fix it
+//
+// static usleep_hook_t usleep_hook;
+//
+// void zynq_set_usleep_hook(usleep_hook_t hook)
+// {
+//  usleep_hook = hook;
+// }
+//
+// int usleep(unsigned long useconds)
+// {
+//  if (usleep_hook)
+//  {
+//      usleep_hook(useconds);
+//      return 0;
+//  }
+
+//  XTime tEnd, tCur;
+
+//  XTime_GetTime(&tCur);
+//  tEnd = tCur + (((XTime) useconds) * COUNTS_PER_USECOND);
+//  do
+//  {
+//      XTime_GetTime(&tCur);
+//  } while (tCur < tEnd);
+
+//  return 0;
+// }
+//
+
+extern void zynq_set_usleep_hook(usleep_hook_t hook);
+
+static void hw_usleep_hook(unsigned long useconds)
+{
+    useconds /= 1000;
+    if (useconds == 0)
+        useconds = 1;
+
+    rt_thread_mdelay(useconds);
+}
+
+static int setup_zynq_usleep_hook(void)
+{
+    zynq_set_usleep_hook(hw_usleep_hook);
+    return 0;
+}
+INIT_BOARD_EXPORT(setup_zynq_usleep_hook);
+
+static void _assert_hook (const char *ex, const char *func, rt_size_t line)
+{
+    RT_ASSERT(0);
+}
+
+/**
+ * This function will initialize beaglebone board
+ */
+void rt_hw_board_init(void)
+{
+    Xil_AssertSetCallback(rt_xil_assert_callback);
+
+    /* initialize hardware interrupt */
+    rt_hw_interrupt_init();
+    /* initialize system heap */
+    rt_system_heap_init(HEAP_BEGIN, HEAP_END);
+
+    rt_hw_pin_init();
+
+    rt_components_board_init();
+
+    rt_console_set_device(RT_CONSOLE_DEVICE_NAME);
+
+    rt_thread_idle_sethook(idle_wfi);
+
+#ifdef RT_USING_SMP
+    /* install IPI handle */
+    rt_hw_ipi_handler_install(RT_SCHEDULE_IPI, rt_scheduler_ipi_handler);
+#endif
+
+    rt_assert_set_hook(_assert_hook);
+}
+
+#include "xil_io.h"
+#define PSS_RST_CTRL_REG 0xF8000200
+#define SLCR_UNLOCK_ADDR 0xF8000008
+#define UNLOCK_KEY 0xDF0D
+#define PSS_RST_MASK 0x01
+
+static void zynq_hw_software_reset(void)
+{
+    Xil_Out32(SLCR_UNLOCK_ADDR, UNLOCK_KEY);
+    Xil_Out32(PSS_RST_CTRL_REG, PSS_RST_MASK);
+}
+MSH_CMD_EXPORT_ALIAS(zynq_hw_software_reset, reboot, soft reboot);

bsp/zynq/zynq7000/drivers/board.h

@@ -0,0 +1,42 @@
+#ifndef __BOARD_H__
+#define __BOARD_H__
+
+#if defined(__CC_ARM)
+extern int Image$$RW_IRAM1$$ZI$$Limit;
+#define HEAP_BEGIN      ((void*)&Image$$RW_IRAM1$$ZI$$Limit)
+#elif defined(__GNUC__)
+extern int __bss_end;
+#define HEAP_BEGIN      ((void*)&__bss_end)
+#endif
+
+#define HEAP_END        (void*)(0x20100000-1)
+#define GIC_IRQ_START  0
+#define MAX_HANDLERS 94
+#define GIC_ACK_INTID_MASK 0x000003ff
+#define ARM_GIC_MAX_NR 1
+#define ARM_GIC_NR_IRQS MAX_HANDLERS
+
+#include "rtthread.h"
+#include "xparameters.h"
+
+#define Zynq7000_GIC_CPU_BASE XPAR_PS7_SCUGIC_0_BASEADDR
+#define Zynq7000_GIC_DIST_BASE XPAR_PS7_SCUGIC_0_DIST_BASEADDR
+
+rt_inline rt_uint32_t platform_get_gic_dist_base(void)
+{
+    return Zynq7000_GIC_DIST_BASE;
+}
+
+rt_inline rt_uint32_t platform_get_gic_cpu_base(void)
+{
+    return Zynq7000_GIC_CPU_BASE;
+}
+
+#define __REG32(x) (*((volatile unsigned int *)(x)))
+#define __REG16(x) (*((volatile unsigned short *)(x)))
+
+void rt_hw_board_init();
+
+int rt_hw_uart_init(void);
+
+#endif

bsp/zynq/zynq7000/drivers/drv_emmc.c

@@ -0,0 +1,373 @@
+#include "xil_exception.h"
+#include "xsdps.h"
+#include <stdio.h>
+#include "xparameters.h"
+#include "rtthread.h"
+#include <rtdevice.h>
+
+#define DBG_TAG "drv.mmc"
+#define DBG_LVL DBG_INFO
+#include <rtdbg.h>
+
+#define EMMC_BLOCK_SIZE (512)
+
+extern u16 TransferMode;
+extern s32 XSdPs_CmdTransfer(XSdPs *InstancePtr, u32 Cmd, u32 Arg, u32 BlkCnt);
+extern void XSdPs_SetupADMA2DescTbl(XSdPs *InstancePtr, u32 BlkCnt, const u8 *Buff);
+
+// replace XSdPs_ReadPolled, using `rt_thread_mdelay`
+s32 XSdPs_ReadPolled_rtt(XSdPs *InstancePtr, u32 Arg, u32 BlkCnt, u8 *Buff)
+{
+    s32 Status;
+    u32 PresentStateReg;
+    u32 StatusReg;
+
+    if ((InstancePtr->HC_Version != XSDPS_HC_SPEC_V3) ||
+                ((InstancePtr->Host_Caps & XSDPS_CAPS_SLOT_TYPE_MASK)
+                != XSDPS_CAPS_EMB_SLOT)) {
+        if(InstancePtr->Config.CardDetect != 0U) {
+            /* Check status to ensure card is initialized */
+            PresentStateReg = XSdPs_ReadReg(InstancePtr->Config.BaseAddress,
+                    XSDPS_PRES_STATE_OFFSET);
+            if ((PresentStateReg & XSDPS_PSR_CARD_INSRT_MASK) == 0x0U) {
+                Status = XST_FAILURE;
+                goto RETURN_PATH;
+            }
+        }
+    }
+
+    /* Set block size to 512 if not already set */
+    if( XSdPs_ReadReg(InstancePtr->Config.BaseAddress,
+            XSDPS_BLK_SIZE_OFFSET) != XSDPS_BLK_SIZE_512_MASK ) {
+        Status = XSdPs_SetBlkSize(InstancePtr,
+            XSDPS_BLK_SIZE_512_MASK);
+        if (Status != XST_SUCCESS) {
+            Status = XST_FAILURE;
+            goto RETURN_PATH;
+        }
+    }
+
+    XSdPs_SetupADMA2DescTbl(InstancePtr, BlkCnt, Buff);
+
+    TransferMode = XSDPS_TM_AUTO_CMD12_EN_MASK |
+            XSDPS_TM_BLK_CNT_EN_MASK | XSDPS_TM_DAT_DIR_SEL_MASK |
+            XSDPS_TM_DMA_EN_MASK | XSDPS_TM_MUL_SIN_BLK_SEL_MASK;
+
+    if (InstancePtr->Config.IsCacheCoherent == 0) {
+        Xil_DCacheInvalidateRange((INTPTR)Buff,
+            BlkCnt * XSDPS_BLK_SIZE_512_MASK);
+    }
+
+    /* Send block read command */
+    Status = XSdPs_CmdTransfer(InstancePtr, CMD18, Arg, BlkCnt);
+    if (Status != XST_SUCCESS) {
+        Status = XST_FAILURE;
+        goto RETURN_PATH;
+    }
+
+    /* Check for transfer complete */
+    do {
+        StatusReg = XSdPs_ReadReg16(InstancePtr->Config.BaseAddress,
+                    XSDPS_NORM_INTR_STS_OFFSET);
+        if ((StatusReg & XSDPS_INTR_ERR_MASK) != 0U) {
+            /* Write to clear error bits */
+            XSdPs_WriteReg16(InstancePtr->Config.BaseAddress,
+                    XSDPS_ERR_INTR_STS_OFFSET,
+                    XSDPS_ERROR_INTR_ALL_MASK);
+            Status = XST_FAILURE;
+            goto RETURN_PATH;
+        }
+
+        // delay 1ms
+        if ((StatusReg & XSDPS_INTR_TC_MASK) == 0U)
+            rt_thread_mdelay(1);
+
+    } while((StatusReg & XSDPS_INTR_TC_MASK) == 0U);
+
+    /* Write to clear bit */
+    XSdPs_WriteReg16(InstancePtr->Config.BaseAddress,
+            XSDPS_NORM_INTR_STS_OFFSET, XSDPS_INTR_TC_MASK);
+    Status = (s32)XSdPs_ReadReg(InstancePtr->Config.BaseAddress,
+            XSDPS_RESP0_OFFSET);
+
+    Status = XST_SUCCESS;
+
+RETURN_PATH:
+    return Status;
+}
+
+// replace XSdPs_WritePolled, using rt_thread_mdelay
+s32 XSdPs_WritePolled_rtt(XSdPs *InstancePtr, u32 Arg, u32 BlkCnt, const u8 *Buff)
+{
+    s32 Status;
+    u32 PresentStateReg;
+    u32 StatusReg;
+
+    if ((InstancePtr->HC_Version != XSDPS_HC_SPEC_V3) ||
+                ((InstancePtr->Host_Caps & XSDPS_CAPS_SLOT_TYPE_MASK)
+                != XSDPS_CAPS_EMB_SLOT)) {
+        if(InstancePtr->Config.CardDetect != 0U) {
+            /* Check status to ensure card is initialized */
+            PresentStateReg = XSdPs_ReadReg(InstancePtr->Config.BaseAddress,
+                    XSDPS_PRES_STATE_OFFSET);
+            if ((PresentStateReg & XSDPS_PSR_CARD_INSRT_MASK) == 0x0U) {
+                Status = XST_FAILURE;
+                goto RETURN_PATH;
+            }
+        }
+    }
+
+    /* Set block size to 512 if not already set */
+    if( XSdPs_ReadReg(InstancePtr->Config.BaseAddress,
+            XSDPS_BLK_SIZE_OFFSET) != XSDPS_BLK_SIZE_512_MASK ) {
+        Status = XSdPs_SetBlkSize(InstancePtr,
+            XSDPS_BLK_SIZE_512_MASK);
+        if (Status != XST_SUCCESS) {
+            Status = XST_FAILURE;
+            goto RETURN_PATH;
+        }
+
+    }
+
+    XSdPs_SetupADMA2DescTbl(InstancePtr, BlkCnt, Buff);
+    if (InstancePtr->Config.IsCacheCoherent == 0) {
+        Xil_DCacheFlushRange((INTPTR)Buff,
+            BlkCnt * XSDPS_BLK_SIZE_512_MASK);
+    }
+
+    TransferMode = XSDPS_TM_AUTO_CMD12_EN_MASK |
+            XSDPS_TM_BLK_CNT_EN_MASK |
+            XSDPS_TM_MUL_SIN_BLK_SEL_MASK | XSDPS_TM_DMA_EN_MASK;
+
+    /* Send block write command */
+    Status = XSdPs_CmdTransfer(InstancePtr, CMD25, Arg, BlkCnt);
+    if (Status != XST_SUCCESS) {
+        Status = XST_FAILURE;
+        goto RETURN_PATH;
+    }
+
+    /*
+     * Check for transfer complete
+     * Polling for response for now
+     */
+    do {
+        StatusReg = XSdPs_ReadReg16(InstancePtr->Config.BaseAddress,
+                    XSDPS_NORM_INTR_STS_OFFSET);
+        if ((StatusReg & XSDPS_INTR_ERR_MASK) != 0U) {
+            /* Write to clear error bits */
+            XSdPs_WriteReg16(InstancePtr->Config.BaseAddress,
+                    XSDPS_ERR_INTR_STS_OFFSET,
+                    XSDPS_ERROR_INTR_ALL_MASK);
+            Status = XST_FAILURE;
+            goto RETURN_PATH;
+        }
+
+        if ((StatusReg & XSDPS_INTR_TC_MASK) == 0U)
+            rt_thread_mdelay(1);
+
+    } while((StatusReg & XSDPS_INTR_TC_MASK) == 0U);
+
+    /* Write to clear bit */
+    XSdPs_WriteReg16(InstancePtr->Config.BaseAddress,
+            XSDPS_NORM_INTR_STS_OFFSET, XSDPS_INTR_TC_MASK);
+
+    Status = XST_SUCCESS;
+
+    RETURN_PATH:
+        return Status;
+}
+
+struct rt_hw_emmc_device {
+    struct rt_device dev;
+    XSdPs emmc;
+    XSdPs_Config *cfg;
+    struct rt_mutex lock;
+    u16 dev_id;
+};
+
+#ifdef BSP_USING_SDIO0
+static struct rt_hw_emmc_device emmc0 = {
+    .dev_id = XPAR_PS7_SD_0_DEVICE_ID,
+};
+#endif
+
+#ifdef BSP_USING_SDIO1
+static struct rt_hw_emmc_device emmc1 = {
+    .dev_id = XPAR_PS7_SD_1_DEVICE_ID,
+};
+#endif
+
+#define __INIT_CHECK_CFG(cfg) \
+    if (Status != XST_SUCCESS) \
+    { \
+        rt_kprintf("EMMC Config '%s' failed: err: %d\n", cfg, Status); \
+        return -RT_EIO; \
+    }
+
+static rt_err_t rt_sdcard_init(rt_device_t dev)
+{
+    RT_ASSERT(dev);
+    struct rt_hw_emmc_device *pdev = rt_container_of(dev, struct rt_hw_emmc_device, dev);
+    RT_ASSERT(pdev != RT_NULL);
+
+    rt_mutex_take(&pdev->lock, RT_WAITING_FOREVER);
+    if (pdev->cfg != RT_NULL)
+    {
+        LOG_I("init '%s' success", pdev->dev.parent.name);
+        rt_mutex_release(&pdev->lock);
+        return RT_EOK;
+    }
+
+    pdev->cfg = XSdPs_LookupConfig(pdev->dev_id);
+    RT_ASSERT(pdev->cfg != RT_NULL);
+    s32 Status = XSdPs_CfgInitialize(&pdev->emmc, pdev->cfg, pdev->cfg->BaseAddress);
+    __INIT_CHECK_CFG("cfg");
+
+    Status = XSdPs_CardInitialize(&pdev->emmc);
+    __INIT_CHECK_CFG("init");
+
+    LOG_I("init '%s' success", pdev->dev.parent.name);
+    rt_mutex_release(&pdev->lock);
+
+    return RT_EOK;
+}
+
+rt_inline rt_uint32_t _emmc_start_addr(struct rt_hw_emmc_device *pdev)
+{
+    return 0;
+}
+
+rt_inline rt_uint32_t _emmc_size(struct rt_hw_emmc_device *pdev)
+{
+    return pdev->emmc.SectorCount;
+}
+
+rt_inline rt_uint32_t _emmc_end_addr(struct rt_hw_emmc_device *pdev)
+{
+    return pdev->emmc.SectorCount;
+}
+
+static rt_err_t rt_sdcard_open(rt_device_t dev, rt_uint16_t oflag)
+{
+    return RT_EOK;
+}
+
+static rt_err_t rt_sdcard_close(rt_device_t dev)
+{
+    return RT_EOK;
+}
+
+static rt_ssize_t rt_sdcard_read(rt_device_t dev, rt_off_t pos, void *buffer, rt_size_t size)
+{
+    s32 status;
+    RT_ASSERT(dev);
+    struct rt_hw_emmc_device *pdev = rt_container_of(dev, struct rt_hw_emmc_device, dev);
+    RT_ASSERT(pdev != RT_NULL);
+
+    pos += _emmc_start_addr(pdev);
+    if (size + pos >= _emmc_end_addr(pdev))
+    {
+        LOG_E("addr out of ranger: %d %d", pos, size);
+        return 0;
+    }
+
+    rt_mutex_take(&pdev->lock, RT_WAITING_FOREVER);
+    status = XSdPs_ReadPolled_rtt(&pdev->emmc, pos, size, buffer);
+    rt_mutex_release(&pdev->lock);
+
+    if (status == XST_SUCCESS)
+        return size;
+
+    rt_kprintf("sdcard read failed: %d\n", status);
+    return 0;
+}
+
+static rt_uint8_t sdio_write_buf[2][EMMC_BLOCK_SIZE] __attribute__((aligned(32)));
+
+static rt_ssize_t rt_sdcard_write(rt_device_t dev, rt_off_t pos, const void *buffer, rt_size_t size)
+{
+    s32 status;
+    rt_ssize_t rt = 0;
+
+    RT_ASSERT(dev);
+    struct rt_hw_emmc_device *pdev = rt_container_of(dev, struct rt_hw_emmc_device, dev);
+    RT_ASSERT(pdev != RT_NULL);
+
+    pos += _emmc_start_addr(pdev);
+    if (size + pos >= _emmc_end_addr(pdev))
+    {
+        LOG_E("addr out of ranger: %d %d", pos, size);
+        return 0;
+    }
+
+    rt_mutex_take(&pdev->lock, RT_WAITING_FOREVER);
+    for (int i = 0; i < size; i++)
+    {
+        rt_memcpy(sdio_write_buf[pdev->dev_id], ((rt_uint8_t *)buffer) + EMMC_BLOCK_SIZE * i, EMMC_BLOCK_SIZE);
+
+        status = XSdPs_WritePolled_rtt(&pdev->emmc, pos + i, 1, sdio_write_buf[pdev->dev_id]);
+
+        if (status != XST_SUCCESS)
+        {
+            rt_kprintf("sdcard write failed: %d\n", status);
+            break;
+        }
+
+        rt++;
+    }
+    rt_mutex_release(&pdev->lock);
+
+    return rt;
+}
+
+static rt_err_t rt_sdcard_control(rt_device_t dev, int cmd, void *args)
+{
+    RT_ASSERT(dev);
+    struct rt_hw_emmc_device *pdev = rt_container_of(dev, struct rt_hw_emmc_device, dev);
+    RT_ASSERT(pdev != RT_NULL);
+
+    if (cmd == RT_DEVICE_CTRL_BLK_GETGEOME)
+    {
+        struct rt_device_blk_geometry *geometry;
+
+        geometry = (struct rt_device_blk_geometry *)args;
+        if (geometry == RT_NULL)
+            return -RT_ERROR;
+
+        geometry->bytes_per_sector = EMMC_BLOCK_SIZE;
+        geometry->block_size = EMMC_BLOCK_SIZE;
+        geometry->sector_count = _emmc_size(pdev);
+    }
+
+    return RT_EOK;
+}
+
+static void _init_emmc_dev(struct rt_hw_emmc_device *pdev, const char *name)
+{
+    rt_mutex_init(&pdev->lock, name, RT_IPC_FLAG_PRIO);
+
+    pdev->dev.type = RT_Device_Class_Block;
+    pdev->dev.init = rt_sdcard_init;
+    pdev->dev.open = rt_sdcard_open;
+    pdev->dev.close = rt_sdcard_close;
+    pdev->dev.read = rt_sdcard_read;
+    pdev->dev.write = rt_sdcard_write;
+    pdev->dev.control = rt_sdcard_control;
+    pdev->dev.user_data = RT_NULL;
+
+    rt_device_register(&pdev->dev, name, RT_DEVICE_FLAG_RDWR | RT_DEVICE_FLAG_STANDALONE);
+}
+
+int rt_hw_emmc_init(void)
+{
+#ifdef BSP_USING_SDIO0
+    _init_emmc_dev(&emmc0, "sd0");
+#endif
+
+#ifdef BSP_USING_SDIO1
+    _init_emmc_dev(&emmc1, "sd1");
+#endif
+
+    return RT_EOK;
+}
+INIT_BOARD_EXPORT(rt_hw_emmc_init);

bsp/zynq/zynq7000/drivers/drv_gpio.c

@@ -0,0 +1,202 @@
+#include <board.h>
+#include "drv_gpio.h"
+#include "rtdevice.h"
+#include "rthw.h"
+
+#include "xparameters.h"
+#include "xgpiops.h"
+
+#define GPIOPS_ID XPAR_XGPIOPS_0_DEVICE_ID
+#define GPIO_INTERRUPT_ID XPAR_XGPIOPS_0_INTR
+
+struct hw_intr_node {
+    rt_slist_t node;
+    rt_uint32_t id;
+    void (*hdr)(void *args);
+    void *args;
+};
+
+static XGpioPs gpio;
+static rt_slist_t intr_list;
+
+rt_inline struct hw_intr_node *_find_intr_node(rt_uint32_t id)
+{
+    struct hw_intr_node *p;
+    rt_slist_for_each_entry(p, &intr_list, node)
+    {
+        if (p->id == id)
+        {
+            return p;
+        }
+    }
+
+    return RT_NULL;
+}
+
+static void intr_handler(int vector, void *param)
+{
+    struct hw_intr_node *p;
+    rt_slist_for_each_entry(p, &intr_list, node)
+    {
+        if (!XGpioPs_IntrGetStatusPin(&gpio, p->id))
+            continue;
+
+        XGpioPs_IntrDisablePin(&gpio, p->id);
+        if (p->hdr)
+            p->hdr(p->args);
+
+        XGpioPs_IntrClearPin(&gpio, p->id);
+        XGpioPs_IntrEnablePin(&gpio, p->id);
+    }
+}
+
+static rt_base_t zynq_pin_get(const char *name)
+{
+    rt_set_errno(-RT_ENOSYS);
+    return -1;
+}
+
+static void zynq_pin_write(rt_device_t dev, rt_base_t pin, rt_uint8_t value)
+{
+    if (pin >= XGPIOPS_DEVICE_MAX_PIN_NUM)
+    {
+        rt_set_errno(-RT_ENOSYS);
+        return;
+    }
+
+    XGpioPs_WritePin(&gpio, pin, value);
+}
+
+static rt_int8_t zynq_pin_read(rt_device_t dev, rt_base_t pin)
+{
+    if (pin >= XGPIOPS_DEVICE_MAX_PIN_NUM)
+    {
+        rt_set_errno(-RT_ENOSYS);
+        return -1;
+    }
+
+    return XGpioPs_ReadPin(&gpio, pin);
+}
+
+static void zynq_pin_mode(rt_device_t dev, rt_base_t pin, rt_uint8_t mode)
+{
+    rt_uint8_t isOutput = (mode == PIN_MODE_OUTPUT) || (mode == PIN_MODE_OUTPUT_OD);
+    XGpioPs_SetDirectionPin(&gpio, pin, isOutput);
+    XGpioPs_SetOutputEnablePin(&gpio, pin, isOutput);
+}
+
+static rt_err_t zynq_pin_attach_irq(struct rt_device *device, rt_int32_t pin,
+                                     rt_uint8_t mode, void (*hdr)(void *args), void *args)
+{
+    u8 irq_type;
+    switch (mode)
+    {
+    case PIN_IRQ_MODE_RISING:
+        irq_type = XGPIOPS_IRQ_TYPE_EDGE_RISING;
+        break;
+
+    case PIN_IRQ_MODE_FALLING:
+        irq_type = XGPIOPS_IRQ_TYPE_EDGE_FALLING;
+        break;
+
+    case PIN_IRQ_MODE_RISING_FALLING:
+        irq_type = XGPIOPS_IRQ_TYPE_EDGE_BOTH;
+        break;
+
+    case PIN_IRQ_MODE_HIGH_LEVEL:
+        irq_type = XGPIOPS_IRQ_TYPE_LEVEL_HIGH;
+        break;
+
+    case PIN_IRQ_MODE_LOW_LEVEL:
+        irq_type = XGPIOPS_IRQ_TYPE_LEVEL_LOW;
+        break;
+
+    default:
+        return -RT_ENOSYS;
+    }
+
+    struct hw_intr_node *node = _find_intr_node(pin);
+    if (node != RT_NULL)
+    {
+        return -RT_EBUSY;
+    }
+
+    node = rt_malloc(sizeof(struct hw_intr_node));
+    if (node == RT_NULL)
+    {
+        return -RT_ENOMEM;
+    }
+
+    XGpioPs_SetIntrTypePin(&gpio, pin, irq_type);
+
+    node->id = pin;
+    node->hdr = hdr;
+    node->args = args;
+
+    rt_slist_append(&intr_list, &node->node);
+
+    return RT_EOK;
+}
+
+static rt_err_t zynq_pin_dettach_irq(struct rt_device *device, rt_base_t pin)
+{
+    struct hw_intr_node *node;
+
+    rt_enter_critical();
+    node = _find_intr_node(pin);
+    if (node != RT_NULL)
+    {
+        rt_exit_critical();
+        return -RT_ERROR;
+    }
+    rt_slist_remove(&intr_list, &node->node);
+    rt_exit_critical();
+
+    rt_free(node);
+
+    return RT_EOK;
+}
+
+static rt_err_t zynq_pin_irq_enable(struct rt_device *device, rt_base_t pin,
+                                     rt_uint8_t enabled)
+{
+    if (enabled)
+    {
+        XGpioPs_IntrEnablePin(&gpio, pin);
+    }
+    else
+    {
+        XGpioPs_IntrDisablePin(&gpio, pin);
+    }
+
+    return RT_EOK;
+}
+
+const static struct rt_pin_ops _zynq_pin_ops =
+{
+    zynq_pin_mode,
+    zynq_pin_write,
+    zynq_pin_read,
+    zynq_pin_attach_irq,
+    zynq_pin_dettach_irq,
+    zynq_pin_irq_enable,
+    zynq_pin_get,
+};
+
+int rt_hw_pin_init(void)
+{
+    XGpioPs_Config *gpiops_cfg_ptr;
+    gpiops_cfg_ptr = XGpioPs_LookupConfig(GPIOPS_ID);
+    RT_ASSERT(gpiops_cfg_ptr);
+
+    RT_ASSERT(
+        XGpioPs_CfgInitialize(&gpio, gpiops_cfg_ptr, gpiops_cfg_ptr->BaseAddr)
+        == 0
+    )
+
+    rt_slist_init(&intr_list);
+    rt_hw_interrupt_install(GPIO_INTERRUPT_ID, intr_handler, RT_NULL, "pin");
+    rt_hw_interrupt_umask(GPIO_INTERRUPT_ID);
+
+    return rt_device_pin_register("pin", &_zynq_pin_ops, RT_NULL);
+}

bsp/zynq/zynq7000/drivers/drv_gpio.h

@@ -0,0 +1,16 @@
+#ifndef __DRV_GPIO_H__
+#define __DRV_GPIO_H__
+
+#include <board.h>
+
+#ifdef __cplusplus
+extern "C" {
+#endif
+
+int rt_hw_pin_init(void);
+
+#ifdef __cplusplus
+}
+#endif
+
+#endif /* __DRV_GPIO_H__ */

bsp/zynq/zynq7000/drivers/drv_spiflash.c

@@ -0,0 +1,446 @@
+#include "xparameters.h"
+#include "xqspips.h"
+
+#define QSPI_DEVICE_ID      XPAR_XQSPIPS_0_DEVICE_ID
+
+#include <rthw.h>
+#include <rtdevice.h>
+#include "board.h"
+
+#define DBG_TAG "drv.spiflash"
+#define DBG_LVL DBG_INFO
+#include <rtdbg.h>
+
+#define WRITE_STATUS_CMD    0x01
+#define WRITE_CMD           0x02
+#define READ_CMD            0x03
+#define WRITE_DISABLE_CMD   0x04
+#define READ_STATUS_CMD     0x05
+#define WRITE_ENABLE_CMD    0x06
+#define FAST_READ_CMD       0x0B
+#define DUAL_READ_CMD       0x3B
+#define QUAD_READ_CMD       0x6B
+#define BULK_ERASE_CMD      0xC7
+#define SEC_ERASE_CMD       0xD8
+#define READ_ID             0x9F
+
+#define COMMAND_OFFSET      0  // FLASH instruction */
+#define ADDRESS_1_OFFSET    1  // MSB byte of address to read or write */
+#define ADDRESS_2_OFFSET    2  // Middle byte of address to read or write */
+#define ADDRESS_3_OFFSET    3  // LSB byte of address to read or write */
+#define DATA_OFFSET         4  // Start of Data for Read/Write */
+#define DUMMY_OFFSET        4  // Dummy byte offset for fast, dual and quad reads
+#define DUMMY_SIZE          1  // Number of dummy bytes for fast, dual and quad reads
+#define RD_ID_SIZE          4  // Read ID command + 3 bytes ID response */
+#define BULK_ERASE_SIZE     1  // Bulk Erase command size */
+#define SEC_ERASE_SIZE      4  // Sector Erase command + Sector address */
+#define OVERHEAD_SIZE       4  // control information: command and address
+
+#define SECTOR_SIZE     0x10000
+#define NUM_SECTORS     0x200
+#define NUM_PAGES       0x10000
+#define PAGE_SIZE       256
+
+static XQspiPs qspi_dev;
+
+static u8 ReadBuffer[PAGE_SIZE + DATA_OFFSET + DUMMY_SIZE];
+static u8 WriteBuffer[PAGE_SIZE + DATA_OFFSET];
+
+static int FlashReadID(void);
+static void FlashQuadEnable(XQspiPs *QspiPtr);
+
+static int init(void)
+{
+    int Status;
+
+    XQspiPs_Config *QspiConfig;
+
+    QspiConfig = XQspiPs_LookupConfig(QSPI_DEVICE_ID);
+    if (QspiConfig == NULL) {
+        LOG_E("lockup failed");
+        return XST_FAILURE;
+    }
+
+    Status = XQspiPs_CfgInitialize(&qspi_dev, QspiConfig,
+            QspiConfig->BaseAddress);
+    if (Status != XST_SUCCESS) {
+        LOG_E("cfg init failed : %d", Status);
+        return XST_FAILURE;
+    }
+
+    XQspiPs_SetOptions(&qspi_dev, XQSPIPS_FORCE_SSELECT_OPTION | XQSPIPS_HOLD_B_DRIVE_OPTION);
+    XQspiPs_SetClkPrescaler(&qspi_dev, XQSPIPS_CLK_PRESCALE_8);
+    XQspiPs_SetSlaveSelect(&qspi_dev);
+    FlashReadID();
+    FlashQuadEnable(&qspi_dev);
+
+    return XST_SUCCESS;
+}
+
+/*****************************************************************************/
+/**
+ *
+ * This function writes to the  serial FLASH connected to the QSPI interface.
+ * All the data put into the buffer must be in the same page of the device with
+ * page boundaries being on 256 byte boundaries.
+ *
+ * @param   QspiPtr is a pointer to the QSPI driver component to use.
+ * @param   Address contains the address to write data to in the FLASH.
+ * @param   ByteCount contains the number of bytes to write.
+ * @param   Command is the command used to write data to the flash. QSPI
+ *      device supports only Page Program command to write data to the
+ *      flash.
+ *
+ * @return  None.
+ *
+ * @note        None.
+ *
+ ******************************************************************************/
+rt_inline void FlashWrite(XQspiPs *QspiPtr, u32 Address, u32 ByteCount, u8 Command)
+{
+    u8 WriteEnableCmd = { WRITE_ENABLE_CMD };
+    u8 ReadStatusCmd[] = { READ_STATUS_CMD, 0 }; /* must send 2 bytes */
+    u8 FlashStatus[2];
+
+    /*
+     * Send the write enable command to the FLASH so that it can be
+     * written to, this needs to be sent as a seperate transfer before
+     * the write
+     */
+    XQspiPs_PolledTransfer(QspiPtr, &WriteEnableCmd, NULL,
+            sizeof(WriteEnableCmd));
+
+    /*
+     * Setup the write command with the specified address and data for the
+     * FLASH
+     */
+    WriteBuffer[COMMAND_OFFSET] = Command;
+    WriteBuffer[ADDRESS_1_OFFSET] = (u8) ((Address & 0xFF0000) >> 16);
+    WriteBuffer[ADDRESS_2_OFFSET] = (u8) ((Address & 0xFF00) >> 8);
+    WriteBuffer[ADDRESS_3_OFFSET] = (u8) (Address & 0xFF);
+
+    /*
+     * Send the write command, address, and data to the FLASH to be
+     * written, no receive buffer is specified since there is nothing to
+     * receive
+     */
+    XQspiPs_PolledTransfer(QspiPtr, WriteBuffer, NULL,
+            ByteCount + OVERHEAD_SIZE);
+
+    /*
+     * Wait for the write command to the FLASH to be completed, it takes
+     * some time for the data to be written
+     */
+    while (1) {
+        /*
+         * Poll the status register of the FLASH to determine when it
+         * completes, by sending a read status command and receiving the
+         * status byte
+         */
+        XQspiPs_PolledTransfer(QspiPtr, ReadStatusCmd, FlashStatus,
+                sizeof(ReadStatusCmd));
+
+        /*
+         * If the status indicates the write is done, then stop waiting,
+         * if a value of 0xFF in the status byte is read from the
+         * device and this loop never exits, the device slave select is
+         * possibly incorrect such that the device status is not being
+         * read
+         */
+        if ((FlashStatus[1] & 0x01) == 0) {
+            break;
+        }
+    }
+}
+
+static int write(long offset, const uint8_t *buf, size_t size)
+{
+    RT_ASSERT(size > 0 && size % PAGE_SIZE == 0 && offset % PAGE_SIZE == 0);
+
+    for (int pos = 0; pos < size; pos += PAGE_SIZE)
+    {
+        rt_memcpy(&WriteBuffer[DATA_OFFSET], &buf[pos], PAGE_SIZE);
+        FlashWrite(&qspi_dev, offset + pos, PAGE_SIZE, WRITE_CMD);
+    }
+
+    return size;
+}
+
+/*****************************************************************************/
+/**
+ *
+ * This function reads from the  serial FLASH connected to the
+ * QSPI interface.
+ *
+ * @param   QspiPtr is a pointer to the QSPI driver component to use.
+ * @param   Address contains the address to read data from in the FLASH.
+ * @param   ByteCount contains the number of bytes to read.
+ * @param   Command is the command used to read data from the flash. QSPI
+ *      device supports one of the Read, Fast Read, Dual Read and Fast
+ *      Read commands to read data from the flash.
+ *
+ * @return  None.
+ *
+ * @note        None.
+ *
+ ******************************************************************************/
+rt_inline void FlashRead(XQspiPs *QspiPtr, u32 Address, u32 ByteCount, u8 Command)
+{
+    /*
+     * Setup the write command with the specified address and data for the
+     * FLASH
+     */
+    WriteBuffer[COMMAND_OFFSET] = Command;
+    WriteBuffer[ADDRESS_1_OFFSET] = (u8) ((Address & 0xFF0000) >> 16);
+    WriteBuffer[ADDRESS_2_OFFSET] = (u8) ((Address & 0xFF00) >> 8);
+    WriteBuffer[ADDRESS_3_OFFSET] = (u8) (Address & 0xFF);
+
+    if ((Command == FAST_READ_CMD) || (Command == DUAL_READ_CMD)
+            || (Command == QUAD_READ_CMD)) {
+        ByteCount += DUMMY_SIZE;
+    }
+    /*
+     * Send the read command to the FLASH to read the specified number
+     * of bytes from the FLASH, send the read command and address and
+     * receive the specified number of bytes of data in the data buffer
+     */
+    XQspiPs_PolledTransfer(QspiPtr, WriteBuffer, ReadBuffer,
+            ByteCount + OVERHEAD_SIZE);
+}
+
+static int read(long offset, uint8_t *buf, size_t size)
+{
+    RT_ASSERT(size > 0 && size % PAGE_SIZE == 0 && offset % PAGE_SIZE == 0);
+
+    for (int pos = 0; pos < size; pos += PAGE_SIZE)
+    {
+        FlashRead(&qspi_dev, offset + pos, PAGE_SIZE, QUAD_READ_CMD);
+        rt_memcpy(&buf[pos], &ReadBuffer[DATA_OFFSET + DUMMY_SIZE], PAGE_SIZE);
+    }
+
+    return size;
+}
+
+/*****************************************************************************/
+/**
+ *
+ * This function erases the sectors in the  serial FLASH connected to the
+ * QSPI interface.
+ *
+ * @param   QspiPtr is a pointer to the QSPI driver component to use.
+ * @param   Address contains the address of the first sector which needs to
+ *      be erased.
+ * @param   ByteCount contains the total size to be erased.
+ *
+ * @return  None.
+ *
+ * @note        None.
+ *
+ ******************************************************************************/
+rt_inline void Erase (XQspiPs *QspiPtr, u32 Address, u32 ByteCount)
+{
+    u8 WriteEnableCmd = { WRITE_ENABLE_CMD };
+    u8 ReadStatusCmd[] = { READ_STATUS_CMD, 0 }; /* must send 2 bytes */
+    u8 FlashStatus[2];
+    int Sector;
+    int total_sector;
+
+    /*
+     * If erase size is same as the total size of the flash, use bulk erase
+     * command
+     */
+    if (ByteCount == (NUM_SECTORS * SECTOR_SIZE)) {
+        /*
+         * Send the write enable command to the FLASH so that it can be
+         * written to, this needs to be sent as a seperate transfer
+         * before the erase
+         */
+        XQspiPs_PolledTransfer(QspiPtr, &WriteEnableCmd, NULL,
+                sizeof(WriteEnableCmd));
+
+        /* Setup the bulk erase command*/
+        WriteBuffer[COMMAND_OFFSET] = BULK_ERASE_CMD;
+
+        /*
+         * Send the bulk erase command; no receive buffer is specified
+         * since there is nothing to receive
+         */
+        XQspiPs_PolledTransfer(QspiPtr, WriteBuffer, NULL,
+        BULK_ERASE_SIZE);
+
+        /* Wait for the erase command to the FLASH to be completed*/
+        while (1) {
+            /*
+             * Poll the status register of the device to determine
+             * when it completes, by sending a read status command
+             * and receiving the status byte
+             */
+            XQspiPs_PolledTransfer(QspiPtr, ReadStatusCmd, FlashStatus,
+                    sizeof(ReadStatusCmd));
+
+            /*
+             * If the status indicates the write is done, then stop
+             * waiting; if a value of 0xFF in the status byte is
+             * read from the device and this loop never exits, the
+             * device slave select is possibly incorrect such that
+             * the device status is not being read
+             */
+            if ((FlashStatus[1] & 0x01) == 0) {
+                break;
+            }
+        }
+
+        return;
+    }
+
+    /*
+     * If the erase size is less than the total size of the flash, use
+     * sector erase command
+     */
+    total_sector = RT_ALIGN(ByteCount, SECTOR_SIZE) / SECTOR_SIZE;
+
+    for (Sector = 0; Sector < total_sector; Sector++) {
+        /*
+         * Send the write enable command to the SEEPOM so that it can be
+         * written to, this needs to be sent as a seperate transfer
+         * before the write
+         */
+        XQspiPs_PolledTransfer(QspiPtr, &WriteEnableCmd, NULL,
+                sizeof(WriteEnableCmd));
+
+        /*
+         * Setup the write command with the specified address and data
+         * for the FLASH
+         */
+        WriteBuffer[COMMAND_OFFSET] = SEC_ERASE_CMD;
+        WriteBuffer[ADDRESS_1_OFFSET] = (u8) (Address >> 16);
+        WriteBuffer[ADDRESS_2_OFFSET] = (u8) (Address >> 8);
+        WriteBuffer[ADDRESS_3_OFFSET] = (u8) (Address & 0xFF);
+
+        /*
+         * Send the sector erase command and address; no receive buffer
+         * is specified since there is nothing to receive
+         */
+        XQspiPs_PolledTransfer(QspiPtr, WriteBuffer, NULL,
+        SEC_ERASE_SIZE);
+
+        /*
+         * Wait for the sector erse command to the
+         * FLASH to be completed
+         */
+        while (1) {
+            /*
+             * Poll the status register of the device to determine
+             * when it completes, by sending a read status command
+             * and receiving the status byte
+             */
+            XQspiPs_PolledTransfer(QspiPtr, ReadStatusCmd, FlashStatus,
+                    sizeof(ReadStatusCmd));
+
+            /*
+             * If the status indicates the write is done, then stop
+             * waiting, if a value of 0xFF in the status byte is
+             * read from the device and this loop never exits, the
+             * device slave select is possibly incorrect such that
+             * the device status is not being read
+             */
+            if ((FlashStatus[1] & 0x01) == 0) {
+                break;
+            }
+        }
+
+        Address += SECTOR_SIZE;
+    }
+}
+
+static int erase(long offset, size_t size)
+{
+    Erase(&qspi_dev, offset, size);
+    return size % SECTOR_SIZE == 0? size : (size / SECTOR_SIZE + 1) * SECTOR_SIZE;
+}
+
+/*****************************************************************************/
+/**
+ *
+ * This function reads serial FLASH ID connected to the SPI interface.
+ *
+ * @param   None.
+ *
+ * @return  XST_SUCCESS if read id, otherwise XST_FAILURE.
+ *
+ * @note        None.
+ *
+ ******************************************************************************/
+static int FlashReadID(void)
+{
+    int Status;
+
+    /* Read ID in Auto mode.*/
+    WriteBuffer[COMMAND_OFFSET] = READ_ID;
+    WriteBuffer[ADDRESS_1_OFFSET] = 0x23; /* 3 dummy bytes */
+    WriteBuffer[ADDRESS_2_OFFSET] = 0x08;
+    WriteBuffer[ADDRESS_3_OFFSET] = 0x09;
+
+    Status = XQspiPs_PolledTransfer(&qspi_dev, WriteBuffer, ReadBuffer, RD_ID_SIZE);
+    if (Status != XST_SUCCESS) {
+        return XST_FAILURE;
+    }
+
+    LOG_I("FlashID=0x%x 0x%x 0x%x\n\r", ReadBuffer[1], ReadBuffer[2], ReadBuffer[3]);
+
+    return XST_SUCCESS;
+}
+
+/*****************************************************************************/
+
+/**
+ *
+ * This function enables quad mode in the serial flash connected to the
+ * SPI interface.
+ *
+ * @param   QspiPtr is a pointer to the QSPI driver component to use.
+ *
+ * @return  None.
+ *
+ * @note        None.
+ *
+ ******************************************************************************/
+static void FlashQuadEnable(XQspiPs *QspiPtr)
+{
+    u8 WriteEnableCmd = { WRITE_ENABLE_CMD };
+    u8 ReadStatusCmd[] = { READ_STATUS_CMD, 0 };
+    u8 QuadEnableCmd[] = { WRITE_STATUS_CMD, 0 };
+    u8 FlashStatus[2];
+
+    if (ReadBuffer[1] == 0x9D) {
+
+        XQspiPs_PolledTransfer(QspiPtr, ReadStatusCmd, FlashStatus,
+                sizeof(ReadStatusCmd));
+
+        QuadEnableCmd[1] = FlashStatus[1] | 1 << 6;
+
+        XQspiPs_PolledTransfer(QspiPtr, &WriteEnableCmd, NULL,
+                sizeof(WriteEnableCmd));
+
+        XQspiPs_PolledTransfer(QspiPtr, QuadEnableCmd, NULL,
+                sizeof(QuadEnableCmd));
+    }
+}
+
+#include "fal.h"
+const struct fal_flash_dev spi_flash =
+{
+    .name       = "spi_flash",
+    .addr       = 0x00000000,
+    .len        = NUM_SECTORS * SECTOR_SIZE,
+    .blk_size   = PAGE_SIZE,
+    .ops        = {init, read, write, erase},
+    .write_gran = PAGE_SIZE,
+};
+
+static int rt_hw_on_chip_flash_init(void)
+{
+    fal_init();
+    return RT_EOK;
+}
+INIT_ENV_EXPORT(rt_hw_on_chip_flash_init);

bsp/zynq/zynq7000/drivers/drv_timer.c

@@ -0,0 +1,44 @@
+#include "rtthread.h"
+
+#include "xparameters.h"
+#include "xscutimer.h"
+
+#define APU_FREQ XPAR_PS7_CORTEXA9_0_CPU_CLK_FREQ_HZ
+#define TIMER_DEVICE_ID XPAR_XSCUTIMER_0_DEVICE_ID
+#define TIMER_IRPT_INTR XPAR_SCUTIMER_INTR
+
+static  XScuTimer timer;
+
+static void rt_hw_timer_isr(int vector, void *param)
+{
+    rt_tick_increase();
+
+    XScuTimer_ClearInterruptStatus(&timer);
+}
+
+int rt_hw_timer_init(void)
+{
+    XScuTimer_Config *cfg;
+    s32 err;
+
+    cfg = XScuTimer_LookupConfig(TIMER_DEVICE_ID);
+    RT_ASSERT(cfg);
+
+    err = XScuTimer_CfgInitialize(&timer, cfg, cfg->BaseAddr);
+    RT_ASSERT(err == XST_SUCCESS);
+
+    err = XScuTimer_SelfTest(&timer);
+    RT_ASSERT(err == XST_SUCCESS);
+
+    rt_hw_interrupt_install(TIMER_IRPT_INTR, rt_hw_timer_isr, RT_NULL, "tick");
+    rt_hw_interrupt_umask(TIMER_IRPT_INTR);
+    XScuTimer_EnableInterrupt(&timer);
+
+    XScuTimer_LoadTimer(&timer, APU_FREQ/2/RT_TICK_PER_SECOND);
+    XScuTimer_EnableAutoReload(&timer);
+
+    XScuTimer_Start(&timer);
+
+    return 0;
+}
+INIT_BOARD_EXPORT(rt_hw_timer_init);

bsp/zynq/zynq7000/drivers/drv_uart.c

@@ -0,0 +1,277 @@
+#include "stdio.h"
+#include "xparameters.h"
+#include "xscugic.h"
+#include "xuartps.h"
+
+#include "board.h"
+#include <rtdevice.h>
+#include <rthw.h>
+
+struct hw_uart_device
+{
+    XUartPs uart;
+    rt_uint32_t irqno;
+    uint16_t dev_id;
+    u32 base_addr;
+    rt_bool_t inited;
+};
+
+#ifdef BSP_USING_UART0
+static struct hw_uart_device _uart_device0 = {
+    .dev_id = XPAR_PS7_UART_0_DEVICE_ID,
+    .irqno = XPAR_XUARTPS_0_INTR,
+    .base_addr = XPAR_PS7_UART_0_BASEADDR,
+    .inited = RT_FALSE,
+};
+#endif
+
+#ifdef BSP_USING_UART1
+static struct hw_uart_device _uart_device1 = {
+    .dev_id = XPAR_PS7_UART_1_DEVICE_ID,
+    .irqno = XPAR_XUARTPS_1_INTR,
+    .base_addr = XPAR_PS7_UART_1_BASEADDR,
+    .inited = RT_FALSE,
+};
+#endif
+
+rt_inline rt_err_t _uart_init(struct hw_uart_device *device)
+{
+    XUartPs_Config *uart_cfg = XUartPs_LookupConfig(device->dev_id);
+    if (NULL == uart_cfg)
+        return XST_FAILURE;
+    int status = XUartPs_CfgInitialize(&device->uart, uart_cfg,
+                                       uart_cfg->BaseAddress);
+    if (status != XST_SUCCESS)
+        return XST_FAILURE;
+
+    status = XUartPs_SelfTest(&device->uart);
+    if (status != XST_SUCCESS)
+        return XST_FAILURE;
+
+    XUartPs_SetOperMode(&device->uart, XUARTPS_OPER_MODE_NORMAL);
+
+    XUartPs_SetFifoThreshold(&device->uart, 1);
+
+    return RT_EOK;
+}
+
+rt_inline void _uart_set_fmt(struct hw_uart_device *device,
+                             struct serial_configure *cfg)
+{
+    XUartPsFormat uart_format;
+    uart_format.BaudRate = cfg->baud_rate;
+    switch (cfg->data_bits)
+    {
+    case 7:
+        uart_format.DataBits = XUARTPS_FORMAT_7_BITS;
+        break;
+    case 6:
+        uart_format.DataBits = XUARTPS_FORMAT_6_BITS;
+        break;
+    default: /* 8 */
+        uart_format.DataBits = XUARTPS_FORMAT_8_BITS;
+        break;
+    }
+    // cfg->bit_order ?
+    switch (cfg->parity)
+    {
+    case PARITY_ODD:
+        uart_format.Parity = XUARTPS_FORMAT_ODD_PARITY;
+        break;
+    case PARITY_EVEN:
+        uart_format.Parity = XUARTPS_FORMAT_EVEN_PARITY;
+        break;
+    default: /** None */
+        uart_format.Parity = XUARTPS_FORMAT_NO_PARITY;
+        break;
+    }
+    switch (cfg->stop_bits)
+    {
+    case STOP_BITS_2:
+        uart_format.StopBits = XUARTPS_FORMAT_2_STOP_BIT;
+        break;
+    default:
+        uart_format.StopBits = XUARTPS_FORMAT_1_STOP_BIT;
+        break;
+    }
+
+    XUartPs_SetDataFormat(&device->uart, &uart_format);
+}
+
+static rt_err_t uart_configure(struct rt_serial_device *serial,
+                               struct serial_configure *cfg)
+{
+    RT_ASSERT(serial != RT_NULL);
+    RT_ASSERT(cfg != RT_NULL);
+    struct hw_uart_device *device
+        = (struct hw_uart_device *)serial->parent.user_data;
+    RT_ASSERT(device != RT_NULL);
+
+    if (!device->inited)
+    {
+        int err = _uart_init(device);
+        if (err != RT_EOK)
+            return err;
+
+        device->inited = RT_TRUE;
+    }
+
+    _uart_set_fmt(device, cfg);
+
+    return RT_EOK;
+}
+
+static void rt_hw_uart_isr(int irqno, void *param)
+{
+    struct rt_serial_device *serial = (struct rt_serial_device *)param;
+    struct hw_uart_device *device
+        = (struct hw_uart_device *)serial->parent.user_data;
+
+    u32 isr_status;
+
+    isr_status
+        = XUartPs_ReadReg(device->uart.Config.BaseAddress, XUARTPS_IMR_OFFSET);
+    isr_status &= XUartPs_ReadReg(device->uart.Config.BaseAddress,
+                                  XUARTPS_ISR_OFFSET);
+
+    if (isr_status & (u32)XUARTPS_IXR_RXOVR)
+    {
+        XUartPs_WriteReg(device->uart.Config.BaseAddress, XUARTPS_ISR_OFFSET,
+                         XUARTPS_IXR_RXOVR);
+    }
+
+    rt_hw_serial_isr(serial, RT_SERIAL_EVENT_RX_IND);
+}
+
+static rt_err_t
+uart_control(struct rt_serial_device *serial, int cmd, void *arg)
+{
+    struct hw_uart_device *pdev;
+
+    RT_ASSERT(serial != RT_NULL);
+
+    pdev = serial->parent.user_data;
+
+    switch (cmd)
+    {
+    case RT_DEVICE_CTRL_CLR_INT:
+        break;
+
+    case RT_DEVICE_CTRL_SET_INT:
+        rt_hw_interrupt_install(pdev->irqno, rt_hw_uart_isr, (void *)serial,
+                                serial->parent.parent.name);
+        rt_hw_interrupt_umask(pdev->irqno);
+
+        XUartPs_SetInterruptMask(&pdev->uart, XUARTPS_IXR_RXOVR);
+        break;
+    }
+
+    return RT_EOK;
+}
+
+static int uart_putc(struct rt_serial_device *serial, char c)
+{
+    struct hw_uart_device *dev;
+
+    RT_ASSERT(serial != RT_NULL);
+    dev = (struct hw_uart_device *)serial->parent.user_data;
+    RT_ASSERT(dev != RT_NULL);
+
+    XUartPs_SendByte(dev->base_addr, c);
+
+    return 1;
+}
+
+static int uart_getc(struct rt_serial_device *serial)
+{
+    struct hw_uart_device *dev;
+
+    RT_ASSERT(serial != RT_NULL);
+    dev = (struct hw_uart_device *)serial->parent.user_data;
+
+    u32 RecievedByte;
+    if (!XUartPs_IsReceiveData(dev->base_addr))
+    {
+        return -1;
+    }
+
+    RecievedByte = XUartPs_ReadReg(dev->base_addr, XUARTPS_FIFO_OFFSET);
+    /* Return the byte received */
+    return RecievedByte;
+}
+
+#ifdef RT_SERIAL_USING_DMA
+static rt_ssize_t dma_transmit(struct rt_serial_device *serial,
+                              rt_uint8_t *buf,
+                              rt_size_t size,
+                              int direction)
+{
+    RT_ASSERT(serial != RT_NULL);
+    struct hw_uart_device *dev
+        = (struct hw_uart_device *)serial->parent.user_data;
+    RT_ASSERT(dev != RT_NULL);
+
+    for (int i = 0; i < size; i++)
+        XUartPs_SendByte(dev->base_addr, buf[i]);
+    rt_hw_serial_isr(serial, RT_SERIAL_EVENT_TX_DMADONE);
+
+    return size;
+}
+#endif
+
+static const struct rt_uart_ops _uart_ops = {
+    uart_configure,
+    uart_control,
+    uart_putc,
+    uart_getc,
+#ifdef RT_SERIAL_USING_DMA
+    dma_transmit,
+#endif
+};
+
+#include "rtthread.h"
+
+#ifdef BSP_USING_UART0
+static struct rt_serial_device _serial0;
+#endif
+
+#ifdef BSP_USING_UART1
+static struct rt_serial_device _serial1;
+#endif
+
+int rt_hw_uart_init(void)
+{
+    struct serial_configure config;
+
+    config.baud_rate = BAUD_RATE_115200;
+    config.bit_order = BIT_ORDER_LSB;
+    config.data_bits = DATA_BITS_8;
+    config.parity = PARITY_NONE;
+    config.stop_bits = STOP_BITS_1;
+    config.invert = NRZ_NORMAL;
+    config.bufsz = RT_SERIAL_RB_BUFSZ;
+
+#ifdef BSP_USING_UART0
+    _serial0.ops = &_uart_ops;
+    _serial0.config = config;
+
+    /* register uart device */
+    rt_hw_serial_register(&_serial0, "uart0",
+                          RT_DEVICE_FLAG_RDWR | RT_DEVICE_FLAG_INT_RX
+                              | RT_DEVICE_FLAG_DMA_TX,
+                          &_uart_device0);
+#endif
+
+#ifdef BSP_USING_UART1
+    _serial1.ops = &_uart_ops;
+    _serial1.config = config;
+
+    rt_hw_serial_register(&_serial1, "uart1",
+                          RT_DEVICE_FLAG_RDWR | RT_DEVICE_FLAG_INT_RX
+                              | RT_DEVICE_FLAG_DMA_TX,
+                          &_uart_device1);
+#endif
+
+    return 0;
+}
+INIT_BOARD_EXPORT(rt_hw_uart_init);

bsp/zynq/zynq7000/drivers/fal_cfg.h

@@ -0,0 +1,36 @@
+/*
+ * Copyright (c) 2006-2018, RT-Thread Development Team
+ *
+ * SPDX-License-Identifier: Apache-2.0
+ *
+ * Change Logs:
+ * Date           Author       Notes
+ * 2018-05-17     armink       the first version
+ */
+
+#ifndef _FAL_CFG_H_
+#define _FAL_CFG_H_
+
+#include <rtconfig.h>
+
+/* ===================== Flash device Configuration ========================= */
+extern const struct fal_flash_dev spi_flash;
+
+/* flash device table */
+#define FAL_FLASH_DEV_TABLE                                          \
+{                                                                    \
+    &spi_flash,                                                      \
+}
+
+/* ====================== Partition Configuration ========================== */
+#ifdef FAL_PART_HAS_TABLE_CFG
+/* partition table */
+#define FAL_PART_TABLE                                                                  \
+{                                                                                       \
+    {FAL_PART_MAGIC_WORD,   "golden",   "spi_flash",            0,   8*1024*1024,  0},  \
+    {FAL_PART_MAGIC_WORD,   "app",      "spi_flash",  8*1024*1024,   8*1024*1024,  0},  \
+    {FAL_PART_MAGIC_WORD,   "data",     "spi_flash", 16*1024*1024,  8*1024*1024,  0},   \
+}
+#endif /* FAL_PART_HAS_TABLE_CFG */
+
+#endif /* _FAL_CFG_H_ */

bsp/zynq/zynq7000/lscript.ld

@@ -0,0 +1,312 @@
+/*******************************************************************/
+/*                                                                 */
+/* This file is automatically generated by linker script generator.*/
+/*                                                                 */
+/* Version: 2018.3                                                 */
+/*                                                                 */
+/* Copyright (c) 2010-2016 Xilinx, Inc.  All rights reserved.      */
+/*                                                                 */
+/* Description : Cortex-A9 Linker Script                           */
+/*                                                                 */
+/*******************************************************************/
+
+_STACK_SIZE = DEFINED(_STACK_SIZE) ? _STACK_SIZE : 0x2000;
+_HEAP_SIZE = DEFINED(_HEAP_SIZE) ? _HEAP_SIZE : 0x2000;
+
+_ABORT_STACK_SIZE = DEFINED(_ABORT_STACK_SIZE) ? _ABORT_STACK_SIZE : 1024;
+_SUPERVISOR_STACK_SIZE = DEFINED(_SUPERVISOR_STACK_SIZE) ? _SUPERVISOR_STACK_SIZE : 2048;
+_IRQ_STACK_SIZE = DEFINED(_IRQ_STACK_SIZE) ? _IRQ_STACK_SIZE : 1024;
+_FIQ_STACK_SIZE = DEFINED(_FIQ_STACK_SIZE) ? _FIQ_STACK_SIZE : 1024;
+_UNDEF_STACK_SIZE = DEFINED(_UNDEF_STACK_SIZE) ? _UNDEF_STACK_SIZE : 1024;
+
+/* Define Memories in the system */
+
+MEMORY
+{
+   ps7_ddr_0 : ORIGIN = 0x100000, LENGTH = 0x20000000
+   ps7_qspi_linear_0 : ORIGIN = 0xFC000000, LENGTH = 0x1000000
+   ps7_ram_0 : ORIGIN = 0x0, LENGTH = 0x30000
+   ps7_ram_1 : ORIGIN = 0xFFFF0000, LENGTH = 0xFE00
+}
+
+/* Specify the default entry point to the program */
+
+ENTRY(_reset)
+
+/* Define the sections, and where they are mapped in memory */
+
+SECTIONS
+{
+.text : {
+   __text_start = .;
+   KEEP (*(.vectors))
+   *(.boot)
+   *(.text)
+   *(.text.*)
+
+   /* section information for finsh shell */
+   . = ALIGN(4);
+   __fsymtab_start = .;
+   KEEP(*(FSymTab))
+   __fsymtab_end = .;
+   . = ALIGN(4);
+   __vsymtab_start = .;
+   KEEP(*(VSymTab))
+   __vsymtab_end = .;
+   . = ALIGN(4);
+
+   /* section information for modules */
+   . = ALIGN(4);
+   __rtmsymtab_start = .;
+   KEEP(*(RTMSymTab))
+   __rtmsymtab_end = .;
+
+   /* section information for initialization */
+   . = ALIGN(4);
+   __rt_init_start = .;
+   KEEP(*(SORT(.rti_fn*)))
+   __rt_init_end = .;
+
+   *(.gnu.linkonce.t.*)
+   *(.plt)
+   *(.gnu_warning)
+   *(.gcc_execpt_table)
+   *(.glue_7)
+   *(.glue_7t)
+   *(.vfp11_veneer)
+   *(.ARM.extab)
+   *(.gnu.linkonce.armextab.*)
+} > ps7_ddr_0
+
+.init : {
+   KEEP (*(.init))
+} > ps7_ddr_0
+
+.fini : {
+   KEEP (*(.fini))
+} > ps7_ddr_0
+
+.rodata : {
+   __rodata_start = .;
+   *(.rodata)
+   *(.rodata.*)
+   *(.gnu.linkonce.r.*)
+   __rodata_end = .;
+} > ps7_ddr_0
+
+.rodata1 : {
+   __rodata1_start = .;
+   *(.rodata1)
+   *(.rodata1.*)
+   __rodata1_end = .;
+} > ps7_ddr_0
+
+.sdata2 : {
+   __sdata2_start = .;
+   *(.sdata2)
+   *(.sdata2.*)
+   *(.gnu.linkonce.s2.*)
+   __sdata2_end = .;
+} > ps7_ddr_0
+
+.sbss2 : {
+   __sbss2_start = .;
+   *(.sbss2)
+   *(.sbss2.*)
+   *(.gnu.linkonce.sb2.*)
+   __sbss2_end = .;
+} > ps7_ddr_0
+
+.data : {
+   __data_start = .;
+   *(.data)
+   *(.data.*)
+   *(.gnu.linkonce.d.*)
+   *(.jcr)
+   *(.got)
+   *(.got.plt)
+   __data_end = .;
+} > ps7_ddr_0
+
+.data1 : {
+   __data1_start = .;
+   *(.data1)
+   *(.data1.*)
+   __data1_end = .;
+} > ps7_ddr_0
+
+.got : {
+   *(.got)
+} > ps7_ddr_0
+
+.ctors : {
+   PROVIDE(__ctors_start__ = .);
+   KEEP(*(SORT(.ctors.*)))
+   KEEP(*(.ctors))
+   KEEP (*(SORT(.init_array.*)))
+   KEEP (*(.init_array))
+   PROVIDE(__ctors_end__ = .);
+} > ps7_ddr_0
+
+.dtors : {
+   __DTOR_LIST__ = .;
+   ___DTORS_LIST___ = .;
+   KEEP (*crtbegin.o(.dtors))
+   KEEP (*(EXCLUDE_FILE(*crtend.o) .dtors))
+   KEEP (*(SORT(.dtors.*)))
+   KEEP (*(.dtors))
+   __DTOR_END__ = .;
+   ___DTORS_END___ = .;
+} > ps7_ddr_0
+
+.fixup : {
+   __fixup_start = .;
+   *(.fixup)
+   __fixup_end = .;
+} > ps7_ddr_0
+
+.eh_frame : {
+   *(.eh_frame)
+} > ps7_ddr_0
+
+.eh_framehdr : {
+   __eh_framehdr_start = .;
+   *(.eh_framehdr)
+   __eh_framehdr_end = .;
+} > ps7_ddr_0
+
+.gcc_except_table : {
+   *(.gcc_except_table)
+} > ps7_ddr_0
+
+.mmu_tbl (ALIGN(16384)) : {
+   __mmu_tbl_start = .;
+   *(.mmu_tbl)
+   __mmu_tbl_end = .;
+} > ps7_ddr_0
+
+.ARM.exidx : {
+   __exidx_start = .;
+   *(.ARM.exidx*)
+   *(.gnu.linkonce.armexidix.*.*)
+   __exidx_end = .;
+} > ps7_ddr_0
+
+.preinit_array : {
+   __preinit_array_start = .;
+   KEEP (*(SORT(.preinit_array.*)))
+   KEEP (*(.preinit_array))
+   __preinit_array_end = .;
+} > ps7_ddr_0
+
+.init_array : {
+   __init_array_start = .;
+   KEEP (*(SORT(.init_array.*)))
+   KEEP (*(.init_array))
+   __init_array_end = .;
+} > ps7_ddr_0
+
+.fini_array : {
+   __fini_array_start = .;
+   KEEP (*(SORT(.fini_array.*)))
+   KEEP (*(.fini_array))
+   __fini_array_end = .;
+} > ps7_ddr_0
+
+.ARM.attributes : {
+   __ARM.attributes_start = .;
+   *(.ARM.attributes)
+   __ARM.attributes_end = .;
+} > ps7_ddr_0
+
+.sdata : {
+   __sdata_start = .;
+   *(.sdata)
+   *(.sdata.*)
+   *(.gnu.linkonce.s.*)
+   __sdata_end = .;
+} > ps7_ddr_0
+
+.sbss (NOLOAD) : {
+   __sbss_start = .;
+   *(.sbss)
+   *(.sbss.*)
+   *(.gnu.linkonce.sb.*)
+   __sbss_end = .;
+} > ps7_ddr_0
+
+.tdata : {
+   __tdata_start = .;
+   *(.tdata)
+   *(.tdata.*)
+   *(.gnu.linkonce.td.*)
+   __tdata_end = .;
+} > ps7_ddr_0
+
+.tbss : {
+   __tbss_start = .;
+   *(.tbss)
+   *(.tbss.*)
+   *(.gnu.linkonce.tb.*)
+   __tbss_end = .;
+} > ps7_ddr_0
+
+.bss (NOLOAD) : {
+   __bss_start = .;
+   *(.bss)
+   *(.bss.*)
+   *(.gnu.linkonce.b.*)
+   *(COMMON)
+   __bss_end = .;
+   _exit = .;
+} > ps7_ddr_0
+
+_SDA_BASE_ = __sdata_start + ((__sbss_end - __sdata_start) / 2 );
+
+_SDA2_BASE_ = __sdata2_start + ((__sbss2_end - __sdata2_start) / 2 );
+
+/* Generate Stack and Heap definitions */
+
+.heap (NOLOAD) : {
+   . = ALIGN(16);
+   _heap = .;
+   HeapBase = .;
+   _heap_start = .;
+   . += _HEAP_SIZE;
+   _heap_end = .;
+   HeapLimit = .;
+} > ps7_ddr_0
+
+.stack (NOLOAD) : {
+   . = ALIGN(16);
+   _stack_end = .;
+   . += _STACK_SIZE;
+   . = ALIGN(16);
+   _stack = .;
+   __stack = _stack;
+   . = ALIGN(16);
+   _irq_stack_end = .;
+   . += _IRQ_STACK_SIZE;
+   . = ALIGN(16);
+   __irq_stack = .;
+   _supervisor_stack_end = .;
+   . += _SUPERVISOR_STACK_SIZE;
+   . = ALIGN(16);
+   __supervisor_stack = .;
+   _abort_stack_end = .;
+   . += _ABORT_STACK_SIZE;
+   . = ALIGN(16);
+   __abort_stack = .;
+   _fiq_stack_end = .;
+   . += _FIQ_STACK_SIZE;
+   . = ALIGN(16);
+   __fiq_stack = .;
+   _undef_stack_end = .;
+   . += _UNDEF_STACK_SIZE;
+   . = ALIGN(16);
+   __undef_stack = .;
+} > ps7_ddr_0
+
+_end = .;
+}
+

bsp/zynq/zynq7000/rtconfig.h

@@ -0,0 +1,263 @@
+#ifndef RT_CONFIG_H__
+#define RT_CONFIG_H__
+
+/* Automatically generated file; DO NOT EDIT. */
+/* RT-Thread Project Configuration */
+
+/* RT-Thread Kernel */
+
+#define RT_NAME_MAX 8
+#define RT_ALIGN_SIZE 8
+#define RT_THREAD_PRIORITY_32
+#define RT_THREAD_PRIORITY_MAX 32
+#define RT_TICK_PER_SECOND 1000
+#define RT_USING_OVERFLOW_CHECK
+#define RT_USING_HOOK
+#define RT_HOOK_USING_FUNC_PTR
+#define RT_USING_IDLE_HOOK
+#define RT_IDLE_HOOK_LIST_SIZE 4
+#define IDLE_THREAD_STACK_SIZE 256
+#define RT_USING_TIMER_SOFT
+#define RT_TIMER_THREAD_PRIO 4
+#define RT_TIMER_THREAD_STACK_SIZE 512
+
+/* kservice optimization */
+
+#define RT_KSERVICE_USING_STDLIB
+#define RT_USING_DEBUG
+#define RT_DEBUGING_COLOR
+#define RT_DEBUGING_CONTEXT
+#define RT_DEBUGING_INIT
+
+/* Inter-Thread communication */
+
+#define RT_USING_SEMAPHORE
+#define RT_USING_MUTEX
+#define RT_USING_EVENT
+#define RT_USING_MAILBOX
+#define RT_USING_MESSAGEQUEUE
+
+/* Memory Management */
+
+#define RT_PAGE_MAX_ORDER 11
+#define RT_USING_MEMPOOL
+#define RT_USING_SMALL_MEM
+#define RT_USING_SMALL_MEM_AS_HEAP
+#define RT_USING_HEAP
+
+/* Kernel Device Object */
+
+#define RT_USING_DEVICE
+#define RT_USING_CONSOLE
+#define RT_CONSOLEBUF_SIZE 128
+#define RT_CONSOLE_DEVICE_NAME "uart0"
+#define RT_VER_NUM 0x50001
+#define RT_USING_CACHE
+#define RT_USING_HW_ATOMIC
+#define RT_USING_CPU_FFS
+#define ARCH_MM_MMU
+#define ARCH_ARM
+#define ARCH_ARM_MMU
+#define ARCH_ARM_CORTEX_A
+#define RT_USING_GIC_V2
+#define ARCH_ARM_CORTEX_A9
+
+/* RT-Thread Components */
+
+#define RT_USING_COMPONENTS_INIT
+#define RT_USING_USER_MAIN
+#define RT_MAIN_THREAD_STACK_SIZE 2048
+#define RT_MAIN_THREAD_PRIORITY 10
+#define RT_USING_MSH
+#define RT_USING_FINSH
+#define FINSH_USING_MSH
+#define FINSH_THREAD_NAME "tshell"
+#define FINSH_THREAD_PRIORITY 20
+#define FINSH_THREAD_STACK_SIZE 4096
+#define FINSH_USING_HISTORY
+#define FINSH_HISTORY_LINES 5
+#define FINSH_USING_SYMTAB
+#define FINSH_CMD_SIZE 80
+#define MSH_USING_BUILT_IN_COMMANDS
+#define FINSH_USING_DESCRIPTION
+#define FINSH_ARG_MAX 10
+
+/* DFS: device virtual file system */
+
+#define RT_USING_DFS
+#define DFS_USING_POSIX
+#define DFS_USING_WORKDIR
+#define DFS_FD_MAX 16
+#define RT_USING_DFS_V1
+#define DFS_FILESYSTEMS_MAX 4
+#define DFS_FILESYSTEM_TYPES_MAX 4
+#define RT_USING_DFS_DEVFS
+
+/* Device Drivers */
+
+#define RT_USING_DEVICE_IPC
+#define RT_UNAMED_PIPE_NUMBER 64
+#define RT_USING_SERIAL
+#define RT_USING_SERIAL_V1
+#define RT_SERIAL_USING_DMA
+#define RT_SERIAL_RB_BUFSZ 64
+#define RT_USING_PIN
+
+/* Using USB */
+
+
+/* C/C++ and POSIX layer */
+
+#define RT_LIBC_DEFAULT_TIMEZONE 8
+
+/* POSIX (Portable Operating System Interface) layer */
+
+
+/* Interprocess Communication (IPC) */
+
+
+/* Socket is in the 'Network' category */
+
+
+/* Network */
+
+
+/* Utilities */
+
+#define RT_USING_ADT
+#define RT_USING_ADT_AVL
+#define RT_USING_ADT_BITMAP
+#define RT_USING_ADT_HASHMAP
+#define RT_USING_ADT_REF
+
+/* RT-Thread Utestcases */
+
+
+/* Hardware Drivers Config */
+
+/* On-chip Peripheral Drivers */
+
+#define BSP_USING_GPIO
+#define BSP_USING_UART
+#define BSP_USING_UART0
+#define SOC_ZYNQ_7000
+#define RT_USING_FPU
+
+/* RT-Thread online packages */
+
+/* IoT - internet of things */
+
+
+/* Wi-Fi */
+
+/* Marvell WiFi */
+
+
+/* Wiced WiFi */
+
+
+/* CYW43012 WiFi */
+
+
+/* IoT Cloud */
+
+
+/* security packages */
+
+
+/* language packages */
+
+/* JSON: JavaScript Object Notation, a lightweight data-interchange format */
+
+
+/* XML: Extensible Markup Language */
+
+
+/* multimedia packages */
+
+/* LVGL: powerful and easy-to-use embedded GUI library */
+
+
+/* u8g2: a monochrome graphic library */
+
+
+/* tools packages */
+
+
+/* system packages */
+
+/* enhanced kernel services */
+
+
+/* acceleration: Assembly language or algorithmic acceleration packages */
+
+
+/* CMSIS: ARM Cortex-M Microcontroller Software Interface Standard */
+
+
+/* Micrium: Micrium software products porting for RT-Thread */
+
+
+/* peripheral libraries and drivers */
+
+/* sensors drivers */
+
+
+/* touch drivers */
+
+
+/* Kendryte SDK */
+
+
+/* AI packages */
+
+
+/* Signal Processing and Control Algorithm Packages */
+
+
+/* miscellaneous packages */
+
+/* project laboratory */
+
+/* samples: kernel and components samples */
+
+
+/* entertainment: terminal games and other interesting software packages */
+
+
+/* Arduino libraries */
+
+
+/* Projects and Demos */
+
+
+/* Sensors */
+
+
+/* Display */
+
+
+/* Timing */
+
+
+/* Data Processing */
+
+
+/* Data Storage */
+
+/* Communication */
+
+
+/* Device Control */
+
+
+/* Other */
+
+
+/* Signal IO */
+
+
+/* Uncategorized */
+
+
+#endif

bsp/zynq/zynq7000/rtconfig.py

@@ -0,0 +1,59 @@
+import os
+
+# toolchains options
+ARCH='arm'
+CPU='cortex-a'
+CROSS_TOOL='gcc'
+
+if os.getenv('RTT_CC'):
+    CROSS_TOOL = os.getenv('RTT_CC')
+
+# only support GNU GCC compiler
+PLATFORM 	= 'gcc'
+EXEC_PATH 	= '/opt/arm-none-eabi-gcc'
+
+if os.getenv('RTT_EXEC_PATH'):
+    EXEC_PATH = os.getenv('RTT_EXEC_PATH')
+
+# BUILD = 'relsase'
+BUILD = 'debug'
+if os.getenv('RTT_BUILD_TYPE'):
+    BUILD = os.getenv('RTT_BUILD_TYPE')
+
+if PLATFORM == 'gcc':
+    # toolchains
+    PREFIX = 'arm-none-eabi-'
+    CC = PREFIX + 'gcc'
+    CXX = PREFIX + 'g++'
+    AS = PREFIX + 'gcc'
+    AR = PREFIX + 'ar'
+    LINK = PREFIX + 'gcc'
+    TARGET_EXT = 'elf'
+    SIZE = PREFIX + 'size'
+    OBJDUMP = PREFIX + 'objdump'
+    OBJCPY = PREFIX + 'objcopy'
+    STRIP = PREFIX + 'strip'
+    DEVICE = ' -Wall -Werror -mcpu=cortex-a9 -mfloat-abi=hard -mfpu=vfpv3 -ffunction-sections -fdata-sections -funwind-tables '
+    CFLAGS = DEVICE
+    AFLAGS = ' -c -fmessage-length=0' + DEVICE + ' -x assembler-with-cpp -D__ASSEMBLY__ -I. '
+    LINK_SCRIPT = 'lscript.ld'
+    LFLAGS = DEVICE + ' -Wl,-Map=zynq7000.map,--gc-sections,-build-id=none -specs=Xilinx.spec -Wl,-T -Wl,%s' % LINK_SCRIPT
+    CXXFLAGS = DEVICE + ' -std=gnu++11 -Woverloaded-virtual -fno-exceptions -fno-rtti'
+
+    CPATH = ''
+    LPATH = ''
+
+    M_CFLAGS = CFLAGS + ' -mlong-calls -fPIC '
+    M_CXXFLAGS = CXXFLAGS + ' -mlong-calls -fPIC'
+    M_LFLAGS = DEVICE + CXXFLAGS + ' -Wl,--gc-sections,-z,max-page-size=0x4' +\
+                                ' -shared -fPIC -nostartfiles -nostdlib -static-libgcc'
+    M_POST_ACTION = STRIP + ' -R .hash $TARGET\n' + SIZE + ' $TARGET \n'
+
+    if BUILD == 'debug':
+        CFLAGS += ' -O0 -gdwarf-2'
+        AFLAGS += ' -gdwarf-2'
+    else:
+        CFLAGS += ' -O3'
+
+    POST_ACTION = OBJCPY + ' -O binary $TARGET rtthread.bin\n' +\
+                SIZE + ' $TARGET \n'
